MPO/APC-MPO/APC Singlemode Patch Cord

The singlemode or multimode MPO fiber cable available from Huihong are multifiber connections used in high-density backplane and Printed Circuit Board (PCB) applications in data and telecommunications systems. The MPO fiber cable connector offers up to 12 times the density of standard connectors, providing significant space and cost savings.

Features
---Low insertion and back reflection loss
---Good exchangeability
---Good durability
---High temperature stability
---Standard: Telcordia GR-326-CORE

Applications

-Telecommunication networks
-Data transmission networks
-Computer networks (Gigabit Ethernet, SoNet, etc. )
-Cabling system
-Interconnection of fiber optic transmission equipments
-ODF of optical transmission systems
-FTTX applications

Specifications

Fiber Type:  OS1(9/125um) OM1(62.5/125um) OM2(50/125um) OM3(10GIG)
Connector Polishing Type:  PC, UPC, APC
Fiber Cable Jacket material:  PVC/LSZH
Standard color: Singlemode :Yellow color, Multimode :Orange color
Cable strain relief (boot) O.D. : 0.9mm/1.8mm/2.0mm/3.0mm
Compliant with JIS C-5973, IEC RoHS
Q.C. : 100% function testing include Insertion loss, Return loss and Connector end face geometry.

Parameter table

Insertion loss   Singlemode: PC/UPC≤0.5dB

                            Multimode  PC/UPC≤0.5 dB

Return loss       Singlemode PC/UPC≥45 dB

                            Multimode   PC/UPC≥20 dB
