mono 240w solar panel

Model: SDSM-240W

Maximum Power(W) 240
Optimum Power Voltage(Vmp) 50.30
Optimum Operatige Current(Imp) 4.77
Open Circuit Voltage(Voc) 59.61
Short Circuit Current(Isc) 5.10
Solar Cell: 125*125 Mono
Number of Cell(pcs) 8*12
Size of Module(mm) 1580*1080*40

Front Glass Thikness(mm) 3.2
Temperature Coefficients of Isc(%)C+0.04
Temperature Coefficients of Voc(%)C-0.38
Temperature Coefficients of Pm(%)C-0.47
Temperature Coefficients of Im(%)C+0.04
Temperature Coefficients of Vm(%)C-0.38
Temperature Range -40C to +85C
Tolerance Wattage(e. G. 5%) ± 5%
Surface Maximum Load Capacity 2400Pa
Allowable Hail Load 23m/s, 7.53g
Weight Per Piece(KG) 19.5
Junction Box Type Pass the TUV Certificate
Bypass Diode Rating(A) 12
Caple & Connector Type Pass the TUV Certificate
Cell Efficiency (%) 16.96%
Module Efficiency (%) 14.28%
Frame(Material Corners, etc. ) 40#
Backing (Brand Type) TPT
Warranty 90% of 10 years, 80% of 25 years.
Standard Test Conditions AM1.5 1000W/m2 25 2C
FF (%) 70-76%

Packing Wooden box
