Angle Protecting Mesh Machine Huagang

FOB Price

Negotiable / Set

5 Sets(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

huagang

Place of Origin

China

Product Description

Angle Bead wire mesh (also named Corner protecting wire mesh) is an innovative external corner protecting wire mesh. It is composed of dowel and pulling-connecting meshes. Pulling-connecting meshes form angles Max 90 degree by passing the dowel. There are circular holes which parallel with the dowel on the pulling-connecting mesh. It can protect and reinforce the external corner and prevent the external corner from falling off, being out of shape, crazing. It has characteristics of low cost, simple structure, easily operated, Ease of application, also has wide practical applicability. Angle bead is made from expanding and stretching galvanized steel or stainless steel. The both expanding wings can mortise with the plaster. It is used in buildings to form smooth, straightness, succinct corners. At the same time it can protect the corners from fragmentation, strike, damage. The common length is 2.4m-3m and it can be also made as clients’ requirements.
1. The composition of steel mesh production line and its characteristics:
Angle bead wire mesh production line is composed of Automatic uncoil equipment, Automatic material-supplying equipments, automatic shaping part, automatic cutting shaping mould, molding roller equipment, automatic cutting device and length fixing device, end product supporting device, electronic control system etc. Its characteristics:
1.The automatic uncoil equipment: full automatic, Full steel structure, Easily to hold materials
2.The automatic shaping machine has high production speed and high equipment stability.
3.The equipment roller uses the high quality raw material, its surface is treated by high frequency quench, polishing to make the roller’s surface hard and smooth so that it can produce high quality panels.
4.Roll shaft uses high quality steels thermal refining to improve the comprehensive mechanism performance such as strength, hardness etc.
5.The main components of electrical control system are all imported components.
6.Automatic uncoil, feed and punch. After taking shape, cut off and make accurate fixed length and position. The ends of the panel are neat and beautiful.
7.The punch forming mould is made from high-speed steel. It applies patent technology and make the mould durable in use and has high accuracy.
8.It has less noise, high work efficiency, attractive appearance, durable structure
(Our technology is continuously renewal; the picture is for reference only, please refers to the real object.)
