Product Description

This type Convey Belt Weaving machine is used to manufacture many specs of Convey Belts. Convey Belts concentrate all advantages of Steel wire Convey Belts. Because of the deep wave inserting wire, all the screw steel wire rods are fixed in the right position so that the mesh belts have even surface and can’t be out of shape. They are mainly used in the mechanical flow operations such as: electronic industry, glass factory, instrument drying, rubber factory etc. Convey Belt machine is easily operated; it is composed of three main parts: machine head, mesh jointing frame, mesh collecting frame. The matched parts: two wire paying off reels, wire leading frame. This machine uses single screw thread coil, cutting, edge folding and counting by manpower.
Overall Dimension: Length*Width*Height: 3.5M*2M*1.5M
Overall Weight: 0.5T
Input Voltage: 380V
Weaving Diameter: 0.5-5.5mm (Adjustable)
Production Capacity: production speed 100m/8 hours
Weaving Aperture: 3-50mm (Adjustable)
Maximum Width: 5m Special machine type can be customized.
Major Parameter of Inserting Wire Strips Equipment
Overall Weight: 0.15T
Input Voltage: 380V
Wire Diameter: 0.5-5.5mm
Aperture:3-50mm
Special Machine Type can be customized (Our technology is continuously renewal; the picture is for reference only, please refer to the real object.)
