Sell Breaker

Place of Origin	China

Model No.:RCCB, MCB, MCCB, ELCB, ACB
Product Origin:China
Brand Name:CHOG
Price Terms:
Payment Terms:T/T
Certification:CE
Description:Main features Combined electronic type RCD/MCD device High breaking capacity: 10KA Line voltage-independent tripping Compatible with standard busbar Twin-purpose terminal (lift/open-mouthed)above and below Switch position indicator red-green Switching toggle (MCB component) in colour designation the rated current Busbar positioning optionally above or below Comprehensive range of accessories suitable for subsequent installation Electrical technical data Standards IEC / EN 61009 Tripping time Instantaneous Type G 10ms delay Rated voltage 230V 50Hz Operational voltage range 196-253V Rated tripping current 30, 100, 300mA Rated non-tripping current 0.5In Sensitivity Type A and type AC Selectivity class 3 Rated breaking capacity 10kA Rated current 6-40A Characteristic B, C Maximum back-up fuse(short circuit) 100A gl(>10kA) Endurance electrical life >4000 operating cycles Mechanical life:>20000 operating cycles
