Product Details

Brand Name	Vcomsky		Place of Origin	China
Model Number	VC-MDR3345

Product Description

Delivery Time:300 sets will be delivered in 3 days
Certification:QC,CE

CIF 352x288 to D1 704x576 CCTV 3G Mobile DVR Bus Recorders

Descriptions

This Mobile DVR supports ?1 or 4 channels of video, 1 channels of audio and gives users the option of selecting recording resolutions from CIF(352x288) to D1 (704x576). The sd card stores recorded video and can be removed and connected to a standard PC to view recorded video. It supports GPS function for optional. This mobile solution comes complete with everything required for simple installation.

This mobile solutions are currently being used in the following applications:

Law Enforcement - Patrol Cars Military - Tanks Emergency – Ambulances, Fire Trucks Public – Buses, Trains, Railways, Subways Commercial – Boats, Heavy Equipment, Limousines, Taxis, Vans Transportation - Freight Liners Aviation – Helicopters, Commercial and Private Aircraft

Features

Provide Video output forplaying-back mode in mainframe. Recording format:D1 and CIF H.264 High Profile video compressionl. Userfriendly player software, easytooperation. The full recording time and date can be showing in the monitordirectly. Support from +8V DC to +32VDC. Applicable for vehicles with +12V or +24V battery.. Auto-run recording afterCF card plug-in and power supplied. Support schedule recording. CF-card isrecommended forbettersafetyand anti- vibration performance. Provide 1-4 set of alarm input ports. Firmware can be upgraded via USB port. Support recording audio, video and G-sensor at the same time. GPS for optional.

Specifications

Item	Parameter	Description
System	Language	Chinse Simplified/Chinese Traditional/English/Japanese/other language could be order
	Interface	Graphical User Interface
	Security	Key ?protected
Video	Video Input	4 channel video input, 1.0Vp-p, 75Ω
	Video Output	1 channel vidoe output, 1.0Vp-p, 75Ω
	Video Standard	PAL (25fps) NTSC (30fps)
Audio	Audio Input	1 channel audio input, 20KΩ
	Audio Output	1 channel audio output, 500Ω
	Output level	1V ~2V, p-p
	Recording mode	Audio and video simultaneously recording
	Compression	AAC
Storage	Video Compression	H.264 High Profile
	Resolution	D1 at ?PAL (100fps), NTSC (120fps)
	Video bitrate	D1: 200Kbps ~ 2Mbps, 3 selectable quality
	Audio bitrate	8KB/s(Compressed)
	Storage	CF card
Alarm	Alarms	1-4 CH
Communication	COM	one RS232 connector for optional
GPS	Support external GPS
