Brand Name	DB		Place of Origin	China
Model Number	According to customer

Product Description

Delivery Time:60days
Certification:CE

11kw Main Motor Power C Purlin Roll Forming Machine for Enterprises Civil Construction

The C purline formed by this C purline forming machine has many advantages: well compressive strength and flatness; automatic measureing, cutting and punching; high-level of automation and conviently installation.
It can be used in the main body stress structure of the large and medium-size enterprises civil construction, like the plant, the warehouse, locomotive shed, hangar, exhibition building, theatre, stadiums, roofing load-bearing load and wall surface support of the arbour.
This machine is composed of manual stacker, the pesestal of the staker, feed leading table, flattening device, hydraulic station, computer control box.

Main parameter:
1. Install size:13500mm*2200mm*1500mm
2. Rollers: 13-15 rows
3. Rolling material: Gcr 15
4. Main motor power:11 KW
5. Hydraulic unit power: 11 KW
6. Pressure of the hydraulic unit: 18-20Mpa
7. Productivity: 9-10 m/min
8. Punching material: Cr12
9. Electric control system: PLC vector inverter
10. Raw material thickness: 1.5-3.0mm
11. Forming standard: 80-300
12./ shaped rib (optional)

Usage:shape purlin	Model	Section size
Usage:shape purlin	Model	h(mm)	b(mm)	c(mm)	t(mm)
	C80	80	40	15	2.0-2.5
	C100	100	40	20	2.0-3.0
	C120	120	50	20	2.0-3.0
	C140	140	50	20	2.0-3.0
	C160	160	70	20	2.0-3.0
	C180	180	60	20	2.0-3.0
	C220	220	80	20	2.0-3.0
	C240	240	70	20	2.0-3.0
	C250	250	80	20	2.0-3.0
	C260	260	80	20	2.0-3.0
	C280
