3kw Main Motor Downspout Roll Forming Machine with 80mm Shaft Diameter

3kw Main Motor Downspout Roll Forming Machine with 80mm Shaft Diameter

Downspout (Down pipe) is a pipe for conveying rain water from a roof or gutter to the ground, also referred to as Leaderpipe, Downpipe, or Drainspout. The downspouts are more and more widely applied in rain water storage solution. Downspout disconnection (sometimes called roof leader disconnection) represents a cost-effective on-site alternative for reducing the volume and cost of stormwater that requires public management. Runoff from residential rooftops is collected by eaves troughs, which are installed along the edge of the roofline. Water collected in the eaves trough is conveyed to ground level by one or more downspouts. Downspouts may then connect directly into the storm sewer system into a combined storm and sanitary sewer system. Disconnecting downspouts brings a number of economic and environmental benefits to the municipality and the homeowner

Our roll forming line of downspout machines run copper, steel, or aluminum. These are also ideal for piping for the HVAC industry for small sizes ductwork.

Main motor power: 7.5kw

Roll stsands: 19

Shaft diameter:80mm

The whole production line is controlled by PLC

The downspout roll forming machine mainly consists of decoiler, roll forming system, cutting equipment, protective guard, hydraulic system, control system and

out table. It can make curve for down pipe to meet the requirement of practical engineering projects.
?

Technological process of downpipe roll forming machine:

Uncoiling---Feeding---Leveling---Punching----Roll forming---Cutting---Products collecting
?

Technical parameters:
Steel thickness: 0.5-0.8mm
Forming speed: 8-10m/min
Roller stands: 20 stand
Roller material: 45# steel, coated with chrome
Main motor power: 3kw
Hydraulic cutting power: 7.5kw
Hydraulic pressure: 12Mpa
Power supply: 380V 50HZ 3 phase
Tolerance: 1.5mm
Material of cutting: Cr12
Control system: PLC with touch screen
Machine net weight: 10T
