100KW Steel Coil Slitting Line Machine with Common Carbon Steel Sheet
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Semiautomatic 380V / 3PH Steel Slitter Line Machinery with Hydraulic Tension Station
-
380V / 3PH Steel Slitter Line Machine with Rolling Shear Type for Steel Coil
-
50HZ / 3PH Steel Coil Slitting Line Machine for Stainless Steel Sheet
-
380V / 50HZ Steel Slitting Lines Machine for Zinc-plating Roll Sheet
-
Wall Panel Steel Sheet Roll Forming Machine in Construction for Outdoor Decoration
-
Roof and Wall Panel Roll Forming Machine with 18 Groups of Roller Station
Product Details
| Brand Name | DB | Place of Origin | China | |
| Model Number | According to profile |
Product Description
Certification:CE
100KW Steel Coil Slitting Line Machine with Common Carbon Steel Sheet
Consist of the slitting line
?COIL CAR
UNCOILER?
HOLD DOWN ROLL
LEVELER
SHEAR
SIDE GUIDE?
?SLITTER?
?SCRAP WINDERS
?LOOP TABLE
?TENSION STATION
?SEPARATOR
?RECOILER
Descriptions:
Components of the 1300 semiautomatic slitting line: coil car, hydraulic decoiler, slitter, hydraulic tension station, hydraulic recoiler
Main parameters:
Size(mm):20000*6000*2000
Material: common carbon steel sheet, zinc-plating roll sheet, stainless steel sheet
Material quality: steel coil
Thickness(mm): 0.2-1.5
Width(mm): 1250
Coil I.D(mm): f508
Coil O.D(mm): f1500
Coil weight: 11t(max)
Slitting product:
Coil I.D: f508mm
Slitting tolerance thickness:1.0mm?.03mm(max)
Slitting burr thickness: 1.0mm=0.03mm(max)
Minimal width :12mm
Slitting number: 20(coil thickness 0.5mm)
16(coil thickness1.5mm)
Electric power: 380V/50HZ/3PH
Capacity: 100KW
Speed: 0-80m/min
Slitting type: rolling shear?
?
