380V Semiautomatic Steel Coil Slitting Line Machine with Common Carbon Steel Sheet
- 0 Kilogram / Kilograms per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Roof Panel Roll Forming Machine with Hydraulic Cutting Type for Building the Steel-structure Large-s
-
Roll Forming Line for Rolling Shutter Slats with Automatic Control Cut-to-length Cutting Mode
-
50HZ , 3 PHASE Rolling Forming Shutter Machinery with Forming Speed 15 m / min
-
Roller Shutter Slates Roll Forming Machine with 7.5kw Main Motor for Rolling Steel Doors
-
Purlin Roll Forming Machine for Mid-scale Construction for Exhibition Center
-
Purlin Roll Forming Machinery with Excellent Anti-bending Property
Product Details
| Brand Name | DB | Place of Origin | China | |
| Model Number | According to profile |
Product Description
Certification:CE
380V Semiautomatic Steel Coil Slitting Line Machine with Common Carbon Steel Sheet
Consist of the slitting line
?COIL CAR
UNCOILER?
HOLD DOWN ROLL
LEVELER
SHEAR
SIDE GUIDE?
?SLITTER?
?SCRAP WINDERS
?LOOP TABLE
?TENSION STATION
?SEPARATOR
?RECOILER
Descriptions:
Components of the 1300 semiautomatic slitting line: coil car, hydraulic decoiler, slitter, hydraulic tension station, hydraulic recoiler
Main parameters:
Size(mm):20000*6000*2000
Material: common carbon steel sheet, zinc-plating roll sheet, stainless steel sheet
Material quality: steel coil
Thickness(mm): 0.2-1.5
Width(mm): 1250
Coil I.D(mm): f508
Coil O.D(mm): f1500
Coil weight: 11t(max)
Slitting product:
Coil I.D: f508mm
Slitting tolerance thickness:1.0mm?.03mm(max)
Slitting burr thickness: 1.0mm=0.03mm(max)
Minimal width :12mm
Slitting number: 20(coil thickness 0.5mm)
16(coil thickness1.5mm)
Electric power: 380V/50HZ/3PH
Capacity: 100KW
Speed: 0-80m/min
Slitting type: rolling shear?
?
