Quartz Crystal Oscillator, Crystal Oscillator
- 3000000 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | HEJ | Place of Origin | China | |
| Model Number | quartz crystals and oscillator |
Product Description
1 COMS Circuit TTL/COMS Compatible
2 Compatible With 14-pin Dual In Line
3 Industry Standard
Crystal Oscillator Series:
|
ITEM |
OSC-FSA 5.0V |
OSC-FSB 3.3V |
REMARK |
||
|
Frequency Range |
0.5MHz to 150.0MHz |
|
|||
|
Frequency Stability * |
±25, ±50 , ±100 ppm |
All Condition |
|||
|
Temperature Range |
Storage Temp. |
-55 to +125 |
|
||
|
Operating Temp. |
0 to +70 |
-40 to +85 option |
|||
|
Power Supply Voltage |
5.0V ± 10% |
3.3V ± 10% |
|
||
|
Supply Current |
0.5MHz≤Freq.24MHz |
20mA max. |
15mA max. |
|
|
|
24MHz≤Freq.50MHz |
30mA max. |
20mA max. |
|
||
|
50MHz≤Freq.<70MHz |
40mA max |
30mA max. |
|
||
|
70MHz≤Freq.≤150MHz |
60mA max |
45mA max |
|
||
|
Output Symmetry at 1/2Vdd. |
40~60% |
45~55% option |
|||
|
Rise Time ( 10%~90%Vdd ) |
10nS max. |
8nS max. |
|
||
|
Fall Time ( 90%~10%Vdd ) |
10nS max. |
8nS max. |
|
||
|
Output Voltage |
VoH |
90% Vdd min |
|
||
|
VoL |
10% Vdd max |
|
|||
|
Output Load ( TTL Load ) |
1~10TTL |
1~5TTL |
|
||
|
Output Load ( CMOS Load ) |
0.5MHz≤Freq.50MHz |
50pF |
30pF |
|
|
|
50MHz≤Freq.<70MHz |
30pF |
15pF |
|
||
|
70MHz≤Freq.≤150MHz |
15pF |
15pF |
|
||
|
Start-up Time |
10mS max |
|
|||
|
Aging |
Fist year ±5ppm |
||||
