Quartz crystal resonator HC-49U

FOB Price

Negotiable / Piece

1000 Pieces(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HEJ		Place of Origin	China
Model Number	HC-49U

Product Description

1 Detailed descriptions

Feature: : Resistance weld ; Low power ; High stability ; Wide frequency range

Electrical Specifications:

Nominal frequency : 1.000-125.000MHZ
Mode of vibration : Fundament 1.0-30.0MHZ ; 3rd Voertone 24.0-60.0MHZ ; 60.0-125.0MHZ
Crt type : AT
Frequency tolerance : 20ppm , 30ppm , 50ppm
Frequency stability : 20ppm , 30ppm , 50ppm
Load capacitance : 8pf-33pf
Shunt capacitance : 7.0pf max
Drive level : 0.01-2.0mw max
Insulation resistance : 500M Min/100 15V DC
Operating temperture : A)-10C--+60C B)-20C--+70C C)-30C--+80C D)-40C--+85C
Aging : <=5ppm/year

ROHS compliant,Pb free

Equivalent Series Resistance:

1.000- 2.000 (MHz) : Fundamental 500 Ohm Max
2.000- 2.456(MHz) :    Fundamental 450 Ohm Max
2.457- 3.000(MHz) :    Fundamental 350 Ohm Max
3.000 - 4.000(MHz) :    Fundamental 90   Ohm Max
4.000- 5.000(MHz) :    Fundamental 70   Ohm Max
5.000- 8.000(MHz) :    Fundamental 60 Ohm Max

8.000-10.000(MHz) : Fundamental 30 Ohm Max

10.000- 50.000(MHz) : Fundamental 25 Ohm Max

24.000-125.000(MHz): Third Overtone 40 Ohm Max

2 Sizes
