Europe Type Butterfly Valve
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China |
Product Description
Wafer Butterfly Valve
·Valve Standard:Comply with EN593/BS5155/MSS SP-67.
·Working Pressure and Temperature
Size 50 to 300,working pressure PN 16/class1 125.
Temperature from -10℃ to 120℃ for EPDM liner.
Temperature from -10℃ to 82℃ for NBR liner.
Temperature from -10℃ to 150℃ for Viton liner.
·Top Flange standard: Comply with ISO5211/1.
·Flange Type:EN1092-2 PN10/PN16/PN25,ANSI B16.1 class1125, ANSI B16.2 class1250,BS10 Table D/E,JIS 10K/16K.
·Operator:Handle or gear operator.
·Materials Specification
|
Part Name |
Material |
EN Spec. |
ASTM Spec. |
|
Body |
Cast Iron |
EN-JL1040 |
A126 class1 B |
|
Shaft |
Stainless Steel |
BS970 420S37 |
AISI 420 |
|
Disc |
Stainless Steel |
BS970 304S15 |
A351 CF8 |
|
Bronze |
EN1982 CC491K |
B62 C83600 |
|
|
DI Nichel Plated or FBE Coated |
EN-JS1050 |
A536 65-45-12 |
|
|
Bushing |
PTFE |
Commercial |
Commercial |
|
Liner |
EPDM/NBR/VITON |
Commercial |
Commercial |
|
O-Ring |
EPDM/NBR/VITON |
Commercial |
Commercial |
