Membrane Switch Panel PET PC
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China |
Product Description
Certification:ISO9001-2000 Certificate
membrane switch keypad is made of PET, PC, rear adhesive is 3M467MP, 3M468MP, or ordinary adhesive, color is based on the Pantone, ?
The membrane switch keypad with high quality and good service ,
Specifications:
Assembled with SMD LED, resistors and connectors
Components are guaranteed without any intermittent problem
In-house 100% functionally tested
Customized designs are welcome
Properties:
Operating voltage: < 35V DC
Operating current: < 100mA
Contact resistance: < 100 Ohms
Open circuit resistance: > 10M Ohms
Operating temperature: -35 to 70 degrees Celsius
Storage temperature: -45 to 90 degrees Celsius
Life expectancy: 500, 000 to 30, 000, 000 cycles
Switch stroke: 0.1 to 0.6mm
Contact bounce: 5 to 30ms
Actuation force tolerance: 20 to 45g
Tactile ratio: FC > 40%
Operating humidity: up to 95% RH
Female, male connector, solder pins and heat seal connectors are available
