Mini Car Rear-view Camera with Auto White Balance and 420TVL Resolution
Negotiable
1 (Min.Order)
- 0 per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
18mm Sony CCD Board Camera Module with 1/4-inch Image Sensor and 12V DC Power Supply
-
Video B/W CMOS Camera Module with 420TVL Horizontal Resolution
-
1/3-inch CCTV Camera Module with OV7949 Image Sensor and 420TVL Horizontal Resolution
-
CCD CCTV Camera Module with 3.6mm x 2.4mm Sensing Area and PAL and NTSC Signal System
-
HD Colored 1/5-inch Video Borescope Camera Module with LED and Four Video
-
1/3-inch Video Door Phone Camera Module with IR Lens, 12V DC and 60mA Power Supply
Product Details
| Brand Name | CCGE | Place of Origin | China | |
| Model Number | CCGE-30165 |
Product Description
Image device: PC1030N
TV system: PAL/NTSC
Effective pixels: 648 x 488
Sensing area: 5.55 x 5.55um
Scanning system: 2:1 interlace
Sync system: internal
Resolution: 420TVL
Horizontal sync frequency: 15.625/15.734KHz
Vertical sync frequency: 50/60Hz
Minimum illumination: 1.5 lux/F1.2
Video output: 1.0vp-p, 75 Ohms
Gamma consumption: 0.45
Viewing angle: 120 or 170° optional
S/N ratio: better than 48dB
White balance: auto
Electronic shutter: 1/60 to 1/15,000 seconds
BLC: auto
Current consumption: 100mA
Power supply: 12V DC
Operating temperature: -10 to 50°C, RH 95% maximum
Storage temperature: -30 to 60°C, RH 95% maximum
Accessories:<ul>
Power cable: 1.5m, one piece
Video cable: 6m, one piece
Screws: two sets
User manual
Retail gift box packaging</ul>
