DDigital Multimeter VICTOR 88D

Basic Function

Range

Basic accuracy

DC Voltage

200mV/2V/20V/200V/1000V

±(0.1%+5)

400mV/4V/40V/400V/1000V

DC Voltage

40mV/400mV

AC Voltage

2V/20V/200V/750V

±(0.8%+25)

400mV/4V/40V/400V/750V

AC Voltage

40mV/400mV

DC Current

200uA/2mA/ 20mA/200mA/20A

±(0.5%+4)

400uA/4mA/40mA/400mA/20A

AC Current

20mA/200mA/20A

±(1.5%+25)

400uA/4mA/40mA/400mA/20A

Resistance

200Ω/2kΩ/20kΩ/200kΩ/2MΩ/200MΩ

±(0.4%+5)

400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ

Capacitance

20nF/2uF/200uF

±(3.5%+10)

40nF/400nF/4uF/40uF/200uF

Frequency

20kHz/200kHz

±(3.0%+150)

100Hz/1000Hz/10kHz/100kHz/1MHz/30MHz

Celsius

(-40~1000)°C

±(0.8%+40)

Fahrenheit

(0~1832)°F

Special Function

Diode test

√

Continuity buzzer

√

Low battery indication

√

Relative value measurement

Max./Min.Value selection

Backlight

√

Data Hold

Auto power off

√

Backlight

Function protection

√

Restorable Fuse protection

√

Shock proof protection

√

Input impedance

10MΩ

Sampling rate

3 times/s

AC Frequency response

40~400Hz

Operation way

Manual range

Max. Display

19999
