wind tower tube welding manipulator

LH5040 manipulator

Lifting stroke??????????????????????????????? Max5000mm min900mm

Extend and withdraw stroke?????? Max4000mm min900mm

Boom feed speed?????????????????????? 120-1200mm/min

Drive of extend and withdraw???? Gear and rack

Lifting speed??????????????????????????????? 1000mm/min

Drive of lifting????????????????????????????? Chain and sprocket

Cross slider??????????????????????????????? 200mm (up and down, back and forward)

Rotating model??????????????????????????? ±180°(Motorized)

Inner rail gauge?????????????????????????? 2000mm

Load capacity at end of boom??? 500KG

Flux recovery capacity :??????? 100KG

Welding power:?? Lincoln DC1000+AC 1200

60T conventional rotator (Motorized traveling)

This equipment is consisting of drive rotator, idler rotator, traveling base, and control system.

Both traveling base have traveling device, it is easy for fitting up of work piece. The rollers are all poly design. As the production line is long. When changing position, you can use fast plug. This design can reduce electric line using, and it is more convenient.

Load capacity????????????? ????? 60T

Vessel size???????????????????? φ1000-5000mm

Roller size???????????????????????? 450×180mm*2

Roller speed????????????????? 100-1000mm/min

Speed control???????????????? Variable frequency

Rotating motor????????????????? 2*2.2KW

Traveling motor??????????? 21.5KW
