welding positioner

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 0 per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin

China

Product Description

Delivery Time:30 days

welding positioner is mainly composed of a working table, turning device, overturn device, electricity conducting device, stande

welding positioner is mainly composed of a working table, turning device, overturn device, electricity conducting device, stander and electric cabinet. The working table is driven by the turning device which has 6 T style slots to ensure the work piece is strictly fastened on the working table.

1. The turning device is made up of a motor, a speed reducer and a swing set.
2. Frequency conversion and speed regulation is used for speed change.
3. Stepless speed regulation, easy control and cheap maintenance.
4. The overturn device is mainly made up of an electric motor, cycloidal gear speed reducer, worm wheel speed reducer, semicircular gear.
5. Either end of the output shaft of the overturn device is installed with a semicircular gear.
6. One end of the electric conduction device is connected to the swing set while the other end has an electric conducting shaft. It is directly propped to the working table, allowing the welding current to be directly transmitted from the working table.
7. The stander is of a box structure, allowing high loading capacity. It is made of Q235-A steel with annealing and finish machining to eliminate the welding stress deformation.

Technical Parameters of HBJ Series Welding Positioner

Model		HBJ-01	HBJ-03	HBJ-06	HJB-12	HBJ-30	HBJ-50	HBJ-100
Rated load capacity (kg)		100	300	600	1200	3000	5000	10000
Turning speed(rpm)		0.4-4	0.1-1	0.09-0.9	0.05-0.5	0.05-0.5	0.05-0.5	0.05-0.2
Overturn speed(rpm)		handle		1.1	0.67	0.23	0.14	0.14
Diameter of working table(mm)		400	600	1000	1200	1400	1500	2000
Turning angle (°)		0-120	0-90	0-90	0-120
Motor power (KW)	Turning	0.06	0.37	0.75	1.1	1.5	3	5.5
Motor power (KW)	Overturning	?	?	0.75	2.2	1.5	3	5.5
Speed regulation Type		Stepless frequency conversion
Max gravity distance(mm)		100	100	100	150	200	300	400
Max eccentricity (mm)		150	150	150	200	200	300	400
Max rotating diameter when 90° overturned (mm)		600	800	1500	2050	2100	2500	3240
