HSOM-1210 12.1'' TFT LCD Open Frame Monitor

Optical Spec

Panel supplier

Sumsung /LG/AU/CMO

Panel size

12.1''

Resolution

1024 x 768@75HZ

Brightness

450 nits

Contrast Ratio

600:1

Pixel Pitch approx:

?0.3075mm (H) x 0.3075mm (V) mm

ViewingAngle ( U/B , L/R)

?L/R 70o/70o, ?? U/B 60o /60o

Response Time

10ms

Colors

16.7M

Hardware Spec

Interface

VGA Input : D-Sub15 pin,

Option interface

DVI, USB, HDMI, S-Video(Optional)

Power

Input : 100 ～240V , 50~60Hz / Output : DC 12V, 3.5A

OSD Control

Auto adjust, Brightness, Contrast, Hori. / Vert. Position, Clock, phase, Color, Language..

Mechanical &

Temperature: -30°C to 80°C Operating / -30°C to 80°C Storage

Environmental

Humidity : 10%RH to 90%RH Operating / 10%RH to 90%RH Storage

Power Consumption

30 Watts ( Max )

Plug & Play

DDC 1/2B

Accessories

15-PIN VGA cable, Power cord, AC adapter, L-bracket

Option

TouchScreen Type

Resistive(4-wire/5-wire), SAW, IR Capacitive

TouchScreen interface

Serial (RS232) or USB(B)

Mounting

Panel-Mount, Rear-Mount, VESA 75mm/100mm , brackets included

Dimension

?300mmx 240mm x50mm

Net weight/Gross weight

TBD

Agency Approval

CE RoHs CCC

Warranty

One year warranty period for each product
