HSTM-1509 15'' 5-wire Resistive Touchscreen Monitor

Optical Spec

Panel

TFT LCD panel

Panel size

15''

Display area

304.128mm(H) * 228.096mm(V)

Resolution

1024 * 768

Brightness

250

Aspect ratio

4:3

Contrast Ratio

500:1

Viewing Angle ( H/V)

160° (H)/160° (V)

Colors

16.7M

Hardware Spec

Interface

VGA Input : D-Sub15 pin,

Optional Interface

DVI. USB. HDMI, Audio, S-Video(Optional)

Power

Input : 100 ～ 240V , 50~60Hz / Output : DC 12V, 3.5A

OSD Control

Auto adjust, Brightness, Contrast, Hori. / Vert. Position, Clock, phase, Color, Language..

Temperature

Temperature: -45°C to 60°C (Operating) / -50°C? to 70°C (Storage )

Humidity

Humidity : 10% RH to 90% RH Operating / 10% RH to 90% RH Storage

Power Consumption

30 Watts ( Max )

Plug & Play

DDC 1/2B

Accessories

(Optional)

15-PIN VGA cable, Audio cables, Power cord, AC adaptor

Touch Screen

Technology

5-wire Resistive touch screen (other options available)

Resolution

4096*4096

Light transmission

>80%

Response time

Less than 10ms

TouchScreen interface

USB /Serial RS232

Mounting

Panel-Mount, Rear-Mount, VESA 75mm/100mm
