LED Backlight 46inch 5.3mm Bezel DID LCD Video Wall Display(HQ460-V,support Touch and Pc)
Negotiable
/ Unit
1 Unit(Min. Order)
- shenzhen
- Credit Card PayPal
You May Like
-
46inch 450 Cd/m2 High Brightness Indoor LCD Display Video Walls (HQ460-V,support Touch and Pc)
-
46inch Super Narrow Bezel Exhibition Lcd Video Wall 2x2 Video Wall (HQ460-V,support Touch and Pc)
-
46inch Lcd Video Wall 1920x1080 LED Backlight(HQ460-V,support Touch and Pc)
-
Hot Sell 46 Inch Ultra Narrow LCD Video Wall,LCD TV Wall(HQ460-V,support Touch and Pc)
-
46inch Full HD 1080p Led Video Wall 2x2 3x3 4x4 (HQ460-V,support Touch and Pc)
-
46inch China Quality Lcd Video Wall With Video Wall Monitors(HQ460-V,support Touch and Pc)
Product Details
| Place of Origin | Guangdong, China | Brand Name | Chimee | |
| Model Number | HQ460-V | Type | Other, DID Screen | |
| Application | Indoor | Panel Size | 46 jnch | |
| Max Resolution | 1920 x 1080 | Viewing Angle | 178°/178°(H/V) | |
| Color | 16.7M | Contrast Ratio | 4000:1 | |
| Brightness | 450cd/m2 | Response Time | 6ms | |
| Input Voltage | AC110V-240V, 50/60HZ |
Product Description
Specifications
46" LCD video wall,1920x1080 full HD, 700cd/m2 brightness,5.3mm super narrow bezel, LED backlight.
certificate:CCC,FCC,CE.
Buying Guides
Product Model:
HQ460-V
LED backlight 46inch 5.3mm Bezel DID LCD video wall display
Product Pictures:
Panel Specifications:
| Specifications | |
| Model No. | HQ460-V |
| Panel Size | 46'' Samsung DID LCD Screen(narrow bezel 5.3mm) |
| Aspect Ratio | 16:9 |
| Max Resolution Support | 1920*1080 |
| Color | 8Bit,16.7M |
| Brightness (nits) | 700cd/m2,500cd/m2 |
| Contrast | 4000:1 |
| Visual Angle (H/V) | 178 |
| Response Time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| Video Wall Processor Secifications | |
| Input | CVBS | 3*BNC inputs, support PAL/NTSC, 2*BNC loop outputs | ||||||||||||||
| VGA | 1* D15 port, support SVGA/XGA/WXGA | |||||||||||||||
| YPbPr | 1* YPbPr Input, Support PAL/NTSC | |||||||||||||||
| Y/C | 2* BNC inputs, support PAL/NTSC | |||||||||||||||
| Output | LVDS | Support single or double LVDS output, and WUXGA(1920*1080) | ||||||||||||||
| Operate Mode | Panel key operation (Need customization) | |||||||||||||||
| Infrared Remote Control Operation | ||||||||||||||||
| Standard RS232 port (provide free control software) | ||||||||||||||||
| Engineering Software | Customized | |||||||||||||||
| Temperature | -20°C ~ 50°C | |||||||||||||||
| Humidity | 5% ~ 95% | |||||||||||||||
| Power Supply | AC 110V ~ 240V, 50/60Hz | |||||||||||||||
| Power Consumption | Max 300W, according to different screen models | |||||||||||||||
| Processor Size | 307×282×53.8 (mm) | |||||||||||||||
| Weight | 19Kg to 45Kg | |||||||||||||||
Product Features:
1.Narrow bezel design ---Industrial grade LCD panel ,high quality ,Practical ,good vision effect.
2.Signal interface rich --- RS232, HDMI,DVI,VGA,Y Pb Pr ,AV
3.HD video wall unit--- High brightness,high contrast,High gamut .
4.Flexible structure design ---easy installation ,extensible,arbitrary combination
5.table performance,suitable working for a long time
Product Functions:
Video wall Project:
Video Wall Application :
Product Package:
Product Certification:
A/S Terms:
1. Online technical support with Skype, Yahoo messenger, MSN, Teamview etc.
2. Free spare parts shipping, after checking by pictures and videos, if we confirm the damage not cause by human, we will ship spare parts to do the replacement for free.
3.Online support and sending user manual for buyer's technician to do the replacement of the damage parts.
♥ If you want to know more about our products and company, welcome to contact us at any time. ♥
Hot-line: 0086-15818572697
Skype ID: lizchimee
Chimee has own factory,can also support OEM and Customization sevice.
