32inch All Size Interacitve Whiteboard,IDB,touch Screen Smart tv for Shcools and Training

Specifications

Model No.

HQ32EW-2M

Panel size

Display area(mm)/mode

1860.48*1046.52mm       16:9

Maximum resolution

1920 x 1080

Display color

16.7M

Pixel Pitch(mm)

0.4845mm

Brightness (nits)

350cd/m2

Contrast

1000:1

Visual angle

178°/178°

Response time

6ms

Horizontal frequency

50-70KHZ

Vertical frequency

56-75KHZ

Life(hrs)

60,000(hrs)

Touch Panel

Specification

Infrared touch

Positioning
accuracy

±2mms

Transmittance

>=92%

Hardness

7H

Click manner

double point/mult-point(optional)

Response time

<=4ms

Output Resolution

8192×8192

Life time

more than 600 million times

Monitor Input and output

Composite video input

3 (BNC×3)

YPbPr input

1 (BNC×3)

S-video

2 (BNCX2)

VGA

1

HDMI

1

DVI

1

Composite video output

2 (BNC×2)

Audio input

2

PC Input and output

VGA output

1

HDMI output

1

USB

4

LAN

1

Earphone,3.5 mm

1

Speaker

2×10W(8 ohm)

Video

Color system

PAL/NTSC/SECAM

Compatible HDMI input/DVI

480P,576P,720P,1080I,1080P

3D Comb filter

-

Video reduction noise

-

OSD display( screen menu display)

Menu language

Chinese/English

Computer (optional )

Main chipset

Intel H61

CPU

D525 ,i3 ,i5 ,i7

Graphics card

Integrated

Audio card

Integrated AC97

Network card

Integrated 10/100/1000M adaptive

Memory

4G

Hard Disk

320G SATA

WIFI

Included

Bluetooth

Optional

Operation system

N/A

Power

Power supply

AC100V~240V,50/60Hz

Maximum power consumption

<=1200W

Standby power consumption

<=3W

Temperature

Working temperature

0°C~50°C

Storage temperature

-10°C~60°C

Working humidity

20%~80%

Storage humidity

5%~95%

Appearance

Cabinet color/appearance

White, black, customized

Cabinet material

SPCC/Aluminum/Customized

Installation

Wall-mount
