Home > Products > Steel Wire > 15.24 mm PC Steel Strand
15.24 mm PC Steel Strand
- Xingang Tianjin China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Steel Grade | SWRH82B, High carton steel wire 82B | Standard | AISI, ASTM, BS, DIN, GB, JIS | |
| Wire Gauge | 15.24 | Place of Origin | Tianjin, China | |
| Type | Other, pc strand | Application | Construction | |
| Alloy Or Not | Non-alloy | Special Use | Cold Heading Steel | |
| Model Number | AL01-6 | Brand Name | efya |
Product Description
Specifications
1.PC Strand 7 wires 3 / 5 '' ASTM A416 1860Mpa2.Actual Tensile Strength above 1860Mpa
3.Material: SWRH82B
15.24 mm PC steel Strand
15.24 mm PC steel Strand
| 1 | Type | PC strand , 7 wires, Left Lay, |
| 2 | Diameter | 15.24 mm , 3/5 inches |
| 3 | Construction | 1*7 low relaxation pc strand |
| 4 | Standard | ASTM A416 |
| 5 | Re. mass per 1000m(kg/1000m) | 775/1102 |
| 6 | Material | 82B |
| 7 | Packing | Standard export packing |
| 8 | Tensile strength | 1860MPa |
Mechanics properties of steel strand - ASTM A 416
| Grade | Nominal diameter | Tolerance | Nominal Area of Section | Weight per 1000 meterS | Minimum Breaking load not less than | Minimum load at 1% Extension | Elongation not less than | The Relaxation at 1000h (initial load to 70% of nominal max load ) (r/%) Not more than | |
| (mm) | (mm) | (m2) | (kg) | (KN) | (KN) | (%) | Low Relaxation | Normal-Relaxation | |
| 70% initial load | 80% initial load | ||||||||
| 250 | 6.4 | ±0.40 | 23.2 | 182 | 40 | 36 | 3.5 | 2.5 | 3.5 |
| 7.9 | 37.4 | 294 | 64.5 | 58.1 | |||||
| 9.5 | 51.6 | 405 | 89 | 80.1 | |||||
| 11.1 | 69.7 | 548 | 120.1 | 108.1 | |||||
| 12.7 | 92.9 | 730 | 160.1 | 144.1 | |||||
| 15.2 | 139.4 | 1094 | 240.2 | 216.2 | |||||
| 270 | 9.5 | 0.65 -0.15 | 54.8 | 432 | 102.3 | 92.1 | 3.5 | 2.5 | 3.5 |
| 11.1 | 74.2 | 582 | 137.9 | 124.1 | |||||
| 12.7 | 98.7 | 775 | 183.7 | 165.3 | |||||
| 15.2 | 140 | 1102 | 260.7 | 234.6 | |||||
Product Description
1.PC Strand 7 wires 3 / 5 '' ASTM A416 1860Mpa
2.Actual Tensile Strength above 1860Mpa
3.Material: SWRH82B
15.24 mm PC steel Strand details
