Home > Products > Rubber Foam > Hospital Mackintosh Rubber Sheet

Hospital Mackintosh Rubber Sheet

FOB Price

Negotiable / Piece

1000 Pieces(Min. Order)

Port shanghai/ningbo
Payment TermsT/T L/C D/P D/A Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	HY
Model Number	mackintosh rubber sheet

Product Description

Specifications

mackintosh rubber sheet
1) waterproof
2).fireproof
3).RoSH,SGS passed
4).fast delivery

hospital mackintosh rubber sheet

mackintosh rubber sheet

Product Features:

1. Effective thermal insulation

Thermal conductivity coefficient is a main physical index to show the material thermal conductivity ability, it is relevant to the material component, density, molecular structure and environment humidity. So, at first, we adopt fully closed cell structure, keep the products density controlled within the best scope, reduce the water absorption rate, insure stable thermal conductivity. On the other hand, we adopt advanced production craft to set a lower thermal conductivity, the initial thermal conductivity coefficient is 0.034w(m.k) Energy saving effect will be obvious for long term operation and low maintenance.

2. High combustion-proof performance

Combustion performance is an important index to measure the security performance of the material. Our product is composed of high grade compound material mixed with plenty of combustion-proof and smoke reduction material. It will not melt when come across the fire. It has low smoke density, low toxicity and self-extinguish.

SBR rubber sheet roll
1.Resistance to industrial oil,acid&alkali
2.Available for gaskets, seal
3.Different color
4.Low price

General type rubber sheet

1. SBR,NR Rubber Sheet

Width : 2000mm(max)

Length : Any length

Thickness : From 1.2mm to 50 mm

Standard Color : Black,Green,Red

Two sides can be smooth, or fabric pattern.
Fabric insertion available for request.

2. Neoprene,Nitrile Rubber Sheet

Width : 1800mm(max)
Length : Any length
Thickness : From 1.2mm to 50 mm
Standard Color : Black,Green,Red

Two sides can be smooth, or fabric pattern.
Fabric insertion available for request

3. EPDM Rubber Sheet

Width : 1800mm(max)
Length : Any length
Thickness : From 1.2mm to 50 mm

Two sides can be smooth, or fabric pattern.
Fabric insertion available for request.

4. Silicon sheet

thickness 2-20mm
width 1-2m
length 1-50m

Color Transparence,Red,Green,Blue etc.

Product Details:

Colorful CR/SBR/NBR Rubber Sheet

NBR/PVC rubber sheet for heat proof

Characteristics of our rubber sheet:
1. Closed-cell Structure.
2. Low and Stable Thermal Conductivity.
3. Low Water Absorption Rate.
4. Good Fireproof and Soundproof Performance.
5. Good Aging Resistance Performance.
6. Simple and Easy Installation.
7. Environmental friendly & Improved IAQ.

Rubber sheet application:
Rubber sheet are widely used as different kinds of vapor pipeline heat preservation, heat insulation in central air conditioning engine room, wind pipeline heat preservation and heat insulation and etc. It has good resisting dew-together capability, sound and shock absorption, low density, thermal conductivity and low water vapor transmissibility.
It is ideal for applications in:
Ductwork
Dual temperature and low pressure steam lines
Process piping
Air-conditioner, including hot gas piping

Technical specifications:
Property	Unit	Value
Density range	kg/m³	50~100
Flammability	-	B1
Oxygen index	%	≥33
Thermal conductivity	-	-
Average tempreture -20°C 0°C 40°C	w(m.k)	≤0.032 ≤0.035 ≤0.037
Moisture resistance factor	-	≥5x10³
Water absorption ratio in vacuum	%	≤10
Dimension stability 105°C ±3°C, 7d	-	≤10
Ozone resistance 200h	%	Good, not cracking
Compress resilience ratio Compression ratio 50% Compression time 72h	%	≥70
Aging resistance	-	150 hours, slight wrinkles, no cracks, holes or distortion
Dimensions	-	Pipes/tubes are in 1.83 mtr or 1.85 mtr length Sheet in rolls 1 mtr or 2 mtr width

Product Description:

Characteristics of various rubber sheet :

Natural Rubber Sheet: High flexibility, good comprehensive physical mechanic performance.
SBR Rubber Sheet: Better wear-resistant and anti-aging function than NR, low prices.
Neoprene Rubber Sheet: Good climate resistant, ozone proof, hot resistance and chemical resistant.
NBR Rubber Sheet: Good oil-resistant, wear-resistant and anti-aging.
EPDM Rubber Sheet: Good antiaging, ozone proof, polar liquid resistant, good electric performance, lightest rubber.
Butyl Rubber Sheet: Low permeability, good anti-aging.
Sillicon Rubber Sheet: Excellent oil and fats resistance and for high temperatureup to 260. High resistant one can reach to 250-270 C.
Viton Rubber Sheet: For high temperature up to 300 C.
