Waterproof Flexible Blue Foam Pipe Insulation

FOB Price

Negotiable / Piece

1000 Pieces(Min. Order)

Port shanghai/ningbo
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	HY
Model Number	blue foam insulation

Product Description

Specifications

blue foam insulation
1) waterproof
2).fireproof
3).RoSH,SGS passed
4).fast delivery

waterproof flexible blue foam pipe insulation

blue foam insulation

high quality flexible insulation product designed for insulating in the field ot heating,ventilating,air-conditioning and refrigerating on the basis of the elastomeric foam with closed-cell structure .Provides efficient method of preventing undersirable heat gain or loss in chilled water systeml,cold and hot water plumbing,refrigerated pipes,air-conditioning ductwork and equipment.

Characteristics:
1. CFC/HCFC free.
2. Low Heating Conductivity.
3. Low Water Absorption Rate.
4. Good Fireproof and Soundproof Performance.
5. Good Aging Resistance Performance.
6. Easy Installation.

PRODUCT DATA
Property		Unit	Value	Test Method
Temperature range		°F (°C)	-297~220 (-183~105)	-
Density range		lbs./ft³(kg/m³)	3.0~6.0 (48~96)	ASTM D1622 or D1667
Thermal conductivity	75°F mean T (24°C)	Btu·in./h·ft²·°F (W/mK)	0.27 (0.039)	ASTM C177 or C518
	90°F mean T (32°C)	Btu·in./h·ft²·°F (W/mK)	0.276 (0.040)
Water vapor permeability		perm-in (kg/m·s·pa)	0.08 (1.16×10-13)	ASTM E96 Procedure A DIN 52615
Flame spread and smoke developed index		-	25/50	ASTM E84, CAN/ULC S 102
			V0	UL94
Water absorption, by volume		%	0.2	ASTM C209
Mold growth		-	meet requirement	UL181
Bacterial resistance			meet requirement	ASTM G22
Fungi resistance			meet requirement	ASTM G21/C1338
Resistance to agent chemical		-	stable performance to agent chemical	-
Ozone resistance		-	good	ASTM D1149
Aging resistance		-	150 hours, slight wrinkles, no cracks, holes or distortion	-
Wall thickness (normal) Sheet/Roll		in (mm)	1/8", 1/4", 3/8", 1/2", 5/8", 3/4", 1", 1-1/4", 1-1/2", 2" (3, 6, 9, 13, 16, 19, 25, 32 , 40, 50)	-
Width, sheet/roll		in (m)	40", 48" (1, 1.22)	-
Length, sheet		ft (m)	36" (0.915)	-
Length, roll		ft (m)	98, 49, 33, 26, 23, 20, 13, 10, 10, 8 (30, 15, 10, 8, 7, 6, 4, 3, 3, 2.5)	-

Packaging:
In plastic bag per roll, standard size as below(Thickness×Width×Length)
1/4 Inch ×1M ×30M
3/8 Inch ×1M ×20M
1/2 Inch ×1M ×14M
5/8 Inch ×1M ×12M
3/4 Inch ×1M ×10M
1 Inch ×1M ×8M
1 1/4 Inch ×1M ×6M
1 5/8 Inch ×1M ×4M
1 7/8 Inch×1M ×3M
The width of 1M to 1.4M is available to provide

1.EN71 test,RoSH,REACH,SGS successfully passed

2.Good quality, Eco-friendly,no smell,no toxic for children

3.Different colors,size,hardness,thickness,very good kind of DIY accessories

4.Various and bright color,follow PANTONE COLOR NUMBER,soft feature

5.OEM accepted

6. Manufactured to customers' requirements

7.Size,shape, color, density,hardness,thickness you may choice

8.Widely used in car industry, electronic industry, medical industry,mobile industry,machinery, etc
