XDF-120A Double-action Hydraulic Stretching Machine
- Xiamen Port China
- T/T
You May Like
Product Details
| Condition | New | CNC or Not | CNC | |
| Power Source | Hydraulic | Place of Origin | Fujian, China | |
| Brand Name | chengyang | Model Number | HD Y41-63D | |
| Voltage | 380 | Power(W) | 7.5 | |
| Weight | 4150 | Dimension(L*W*H) | 1200*1600*2100 | |
| Certification | CE |
Product Description
XDF-120A Double-action Hydraulic Stretching Machine
Main Technical Parameter:
Nominal | Main Cylinder | Ton | 85 |
Bottom Cylinder | Ton | 35 | |
Press Cylinder | Ton | 3 | |
Max. Hydraulic | Main Cylinder | Mpa | 23 |
Bottom Cylinder | Mpa | 23 | |
Max. Travel | Main Cylinder | mm | 450 |
Bottom Cylinder | mm | 200 | |
Press Cylinder | mm | 180 | |
Distance Between | mm | 730 | |
Main Cylinder Speed | Downward | mm/s | 220 |
Stretching | mm/s | 12-20 | |
Return Trip | mm/s | 220 | |
Bottom Cylinder | Liftout | mm/s | 115 |
Back | mm/s | 120 | |
Distance Between | mm | 1060 | |
Effective are | L-R | mm | 500 |
F-B | mm | 600 | |
Motor Power | KW | 15 | |
Machine Size | L-R | mm | 1784 |
F-B | mm | 1350 | |
Height | mm | 2915 | |
Total Weight | Kg | 4500 | |
