YXS1011H-2*10P 1.0mm luminous diode connector

Specifications

Specifications :
Current Rating : 1A AC,DC
Voltage Rating : 50V AC,DC
Temperature Range : -25 deg C ~+85 deg C
Contact Resistance : 20m Omega Max.
Insulation Resistance : 100M Omega Min.
Withstanding Voltage : 500V AC/minute
*Contact YXS for detals*"

Housing
part No:YXS1011H-2*XXP
poles:2-20P
Material:PBT+15% Glass Fiber UL94V-0
Packing Q'TY:1000pcs/bag
Mates With YXS1001WV- Series Single Row Wafer

Terminal
Part No:YXS1011-T
Thickness:0.15mm
Material:Phosphor bronze
Finish:Tin Plated
Wire Range:AWG#28-#32
Insulation O.D. : 0.8mm
Q'TY:20,000pcs/reel
Mates With YXS1001H- Series Housing

Please carefully read below YXS TECHNOLOGY CO., LTD.  terms.

Payment method:

Paypal & Credit card & Bank Wire (TT) & Western Union& Escrow service

Customs duty & Handing fee:

We do not charge handing fee . When parts arrived at buyer’s local custom, we do not responsible for any incurred custom duty or import tax .

 Refunds & Return:

 We offer 60 days warranty for all parts. Products will be tested before shipment to ensure they are in good condition.

Buyer must contact us before returning any parts. All returns must be made within 14 days from this shipment date. Return must be in new condition(the SAME CONDITION as it was sent to you).

The buyer is responsible for all shipping cost.

 Shipping:

1. Parts normally will be shipped out within 3 working days after the payment is arrived.

2. Parts can be shipped by DHL/FedEx /TNT/ UPS /EMS or other special method.  Lowest international shipping fee starts from us$4.00(Registered mail).

3. We offer two kinds of shipping method:

Shipping fee of HK air post as below:

Expedited Int'l Shipping (FEDEX, DHL, TNT, EMS)

* According to different countries and regions your address maybe remote area, we have the right to charge an additional remote cost below:

• UPS:   Remote area refer UPS website

• DHL:   Remote area refer  DHL website

• Fedex: Remote area refer FEDEX website

• TNT:   call your local TNT

• Delivery time

For special countries  TNT, EMS will spend 10-15 working days.
