Underground Mining Electric Locomotive
- Qingdao Shanghai Ningbo Shenzhen
- T/T Credit Card
You May Like
Product Details
| Fuel Type | Electric | Horsepower | 2*63kw | |
| Dimensions (L x W x H) (mm) | 5300*1500*1750mm | Speed (km/h) | 25 Km/h | |
| Place of Origin | Shandong, China | Brand Name | China Coal | |
| Model Number | CJY20/7GP trolley locomotive |
Product Description
Underground Mining Electric Locomotive Introduction
Features
l Great tractive effort
l Heavy duty loading capacity
l Smoothly climbing and moving
l Safe braking control system
l Reliable and easy operation
l Simple maintenance
l 25-30% energy saving compared to DC driving type
l Less emission, Eco-Friendly
Underground Mining Electric Locomotive Parameter
Specifications | CJY20/6GP | CJY20/7GP | CJY20/9GP |
Adhesive Total Weight (t) | 20 | 20 | 20 |
Track Gauge (mm) | 600 | 762 | 900 |
Wheelbase (mm) | 1700 | 1700 | 1700 |
Wheel Diameter Over Tread | 760 | 760 | 760 |
Coupler Height over Steel Rail(mm) | 320/430 | 320/430 | 320/430 |
Min Curve radius (m) | 15 | 15 | 15 |
Pantograph Operation Height (mm) | 1800-2400 | 1800-2400 | 1800-2400 |
Braking Method | Mechanical&Electrical+Air | Mechanical&Electrical+Air | Mechanical&Electrical+Air |
Max Tractive Effort (KN) | 54.9 | 54.9 | 54.9 |
Max Speed (km/h) | 25 | 25 | 25 |
Rated Speed (km/h) | 9.3 | 9.3 | 9.3 |
Power of Traction (kw) | 2*63 | 2*63 | 2*63 |
DC Input Power Voltage | DC550/750 | DC550/750 | DC550/750 |
Transmission | Dual Bevel Gearing | Dual Bevel Gearing | Dual Bevel Gearing |
Controller | AC Frequency Conversion | AC Frequency Conversion | AC Frequency Conversion |
Over all Dimensions (mm) | 5300*1200*1750 | 5300*1500*1750 | 5300*1500*1750 |
Service & Application | Mucking in Mining&Tunneling | Mucking in Mining&Tunneling | Mucking in Mining&Tunneling |
Underground Mining Electric Locomotive Photos
