Brass Large Diameter Gate Valves Water 3 Inch Solenoid Valve
US$ 20 - 50
/ Piece
50 Pieces(Min. Order)
- Tianjin/Ningbo
- T/T Credit Card
You May Like
-
DN15 PTFE Seat SS304 Thread Connect Pneumatic Angle Seat Valve
-
Normally Closed Stainless Steel Flange Pneumatic Angle Seat Valve
-
3/4" Brass Piston Type Pressure Reducing Valve
-
Brass Ball Valve Single Union PPR Threaded Ends Full Port /water Contral Valve
-
NLD Hot Sale Stainless Steel 304/316 Sanitary Manual Pneumatic Diaphragm Valve
-
Wafer Type Pneumatic Metal Seat Butterfly Valve
Product Details
| Standard or Nonstandard | Standard | Structure | Gate | |
| Pressure | Medium Pressure | Power | Solenoid | |
| Material | Brass | Temperature of Media | Medium Temperature | |
| Media | Water | Port Size | DN50-DN600 | |
| Place of Origin | Shanxi, China | Model Number | Solenoid Valve | |
| Brand Name | NLD | Application | Other, General, Sewage |
Product Description
| Pattern: | Two-port two-position | |||
| Principium: | pilot diaphragm type | |||
| Control mode: | normally close / normally open | |||
| Valve body: | cast iron | |||
| Diaphragm material: | NBR: <80°C | |||
| Working pressure: | 0.5~8bar | |||
| Max pressure: | 10bar | |||
| Voltage: | AC220V AC110V DC12V DC24V | |||
| Medium: | air ,water , hot water ,oil ect | |||
| Application: | medium-pressure large-flow normally air water control system | |||
| Model | Pipe Flange | Orifice Diameter(mm) | Principium | Work pressure ( bar ) | Cv | Body material | |
| PM-40F | 1.5" | 40 | pilot | NC | NO | 21 | Cast iron |
| 0.5-8 | 0.5-8 | ||||||
| PM-50F | 2" | 50 | 30 | ||||
| PM-65F | 2.5" | 65 | 52.5 | ||||
| PM-80F | 3" | 80 | 81.7 | ||||
| PM-100F | 4" | 100 | 128.4 | ||||
| PM-125F | 5" | 125 | 221.7 | ||||
| PM-150F | 6" | 150 | 291.7 | ||||
| PM-200F | 8" | 200 | 513.5 | ||||
(MM)
| Model | L | H | D | D1 | D2 |
| 40 | 169 | 196 | 150 | Φ110 | 4-Φ18 |
| 50 | 201 | 200 | 165 | Φ125 | 4-Φ18 |
| 65 | 259 | 280 | 185 | Φ145 | 4-Φ18 |
| 80 | 280 | 287 | 200 | Φ160 | 8-Φ18 |
| 100 | 352 | 330 | 220 | Φ180 | 8-Φ18 |
| 125 | 430 | 437 | 250 | Φ210 | 8-Φ18 |
| 150 | 454 | 460 | 285 | Φ240 | 8-Φ22 |
| 200 | 573 | 547 | 340 | Φ295 | 12-Φ22 |
