Home > Products > Plastic drainage board > 12mm Height Dimple Board
12mm Height Dimple Board
- Qingdao
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | starring | |
| Model Number | starring |
Product Description
12mm height dimple board
12mm height dimple board Introduction:
drainage board for treatment of soft foundation is made of a core board with drainage grooves and upper and lower non-woven cloth filtering films and features that the filtering films and the core boaed are produced into one intergral through a thermally welding process.with high strength and reliable drainage,the present invention may be used in drainage of various kinds of foundation, including deep foundation.
Drainage sheet is used for waterproof and drainage for tunnels,subway,underground project,especially suit for leakage on joint.It sets in waterproof and drainage together,which can resolves the waterproofing and drainage relations successfully.
12mm height dimple board Features :
1. Durable, resist compression but light weight
2. Strong drainage capacity
3. Soundproofing, waterproofing and dampproofing
4. Saving investment, and environmental protection for your projects
12mm height dimple board Index
No. | Item | Value | |||||
1 | Model | H10-1.0 | H20-1.0 | H10-1.5 | H20-1.5 | H10-2.0 | H20-2.0 |
2 | Tensile strength,N/5cm | 400 | 400 | 500 | 500 | 700 | 700 |
3 | Break Elongation,% | 200 | 200 | 300 | 300 | 400 | 400 |
4 | Stereo tensile strength | 400 | 320 | 450 | 370 | 500 | 420 |
5 | Dimensional stability,% | ±2 | |||||
6 | Bending at low temperature | Bending without crack at -35°C | |||||
7 | Vertical water flow rate.cm3/s Water pressure is 5KPa | 5.6 | 8.6 | 5.6 | 8.6 | 5.6 | 8.6 |
8 | Vertical water flow rate.cm3/s Water pressure is 5KPa | 15.2 | 18.2 | 15.2 | 18.2 | 15.2 | 18.2 |
Pls feel free to contact us:
