3 Inch Chemical Water Pump Marine Sea Water Pump With 168F Gasoline Engine
- Chongqing
- T/T
You May Like
-
China Brand Mini Water Pump Small Petrol Water Pump
-
168F High Pressure Water Pump Single Impeller Water Pump Made in China
-
5.5hp 3 Inch Water Pump Sewage Water Pump Sump Pump Made in China
-
3 Inch High Lift Water Pump Pressure Water Pump Manufactured in China
-
Juanyong Brand 3 Inch Sea Chemical Water Pump Diesel Engine Water Pump Set
-
Juanyong Brand 1.5 Inch Mini High Pressure Water Pump Diesel Water Pump for Farm
Product Details
| Place of Origin | Chongqing, China | Brand Name | Juanyong | |
| Model Number | FIB80 | Theory | Centrifugal Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Hydraulic | Standard or Nonstandard | Standard | |
| Fuel | Gasoline | Pressure | Low Pressure | |
| Application | Other, marine |
Product Description
Company Information
Tianzhiyuan Machinery Company has been in water pumps industry close to 7 years. Tianzhiyuan provide self-priming water pumps for a wide range of water supply applications- agricultural irrigation, orchard cultivation, drinking water, forestry and firework. Put our advance water pumps and innovation to the world. Tianzhiyuan Machinery Company within concentrated operation of self-priming water pump, include farm irrigation high lift self priming pump, water pumps with 2-6 inches, self priming clear water pump, self priming dirty pumps, high lift water pump, chemical pump/ agriculture irrigation water pump, sewage water pump and related machine components. Tianzhiyuan water pumps have been sold to more than 40 countries all over the world.
Product Description
We specilize in water pump for many years, which has enjoyed great popularity in world market.This kind of chemical pump is designed for irrigation with 168F engine, which can work efficiently and stably.
Performance curve
Parameter
ITEM | FTB80 |
Outlet Size(mm) | 80 |
Inlet Size(mm) | 80 |
Speed(rpm) | 3600 |
Displacement Q.max(m3/h) | 50 |
Lift H.max(m) | 22 |
Suction(m) | 7 |
Engine Model | 168F |
Serial number | Name
| Number
|
1 | Water pump cover | 1 |
2 | Rubber ring φ12×φ6×3.1 | 4 |
3 | Bolt M8×35 | 4 |
4 | Pump sealing ring | 1 |
5 | Mechanical seal / ceramic | 1 |
6 | Impeller | 1 |
7 | Eddy shell | 1 |
8 | Eddy shell sealing ring | 1 |
9 | Water pump body | 1 |
10 | Inlet joint | 2 |
11 | The water outlet joint | 1 |
12 | Threaded plug pump | 2 |
13 | Pipe joint connecting nut | 2 |
14 | Pipe joint | 2 |
15 | Clamp | 3 |
16 | Filter cover | 1 |
17 | Pipe joint sealing gasket | 2 |
18 | Bolt M8×35 | 2 |
19 | Nut M8 | 2 |
20 | Bolt M6×65 | 10 |
21 | Shim | 20 |
22 | Spring pad | 10 |
23 | Nut M6 | 10 |
