Bourdon tube pressure gauge

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Port xi'an
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Germany		Brand Name	WIKA
Model Number	111.10

Product Description

Bourdon tube pressure gaugeModel 111.10, lower mount (LM)

Applications
1: For gaseous and liquid media that are not highly viscous
or crystallising and will not attack copper alloy parts
2:Pneumatics
3: Heating and air-conditioning technology
4:Medical engineering

Description

Design
EN 837-1
Nominal size in mm
40, 50, 63, 80, 100 and 160
Accuracy class
2.5
Scale ranges
0 to 0.6 to 0 to 400 bar (NS 160: max. 40 bar)
or all other equivalent vacuum or combined pressure and
vacuum ranges
Pressure limitation
Steady: 3/4 x full scale value
Fluctuating: 2/3 x full scale value
Short time: Full scale value
Permissible temperature
Ambient: -40 ... +60 °C
Medium: +60 °C maximum
Temperature effect
When the temperature of the measuring system deviates
from the reference temperature (+20 °C): max. ±0.4 %/10 Kof the span
Mechanical
pressure measurement
Standard version
Process connection
Cu-alloy,
lower mount (LM)
NS 40: G 1/8 B (male), 14 mm flats
NS 50,63: G 1/4 B (male), 14 mm flats
NS 80, 100, 160: G 1/2 B (male), 22 mm flats
Pressure element
Cu-alloy,
≤ 60 bar: C-type
> 60 bar: Helical type
Dial
NS 40, 50, 63: Plastic, white, with pointer stop pin
NS 80, 100, 160: Aluminium, white, with pointer stop pin
Black lettering, red mark pointer with measuring ranges
0 ... 0.6 to 0 ... 60 ba
