Home > Products > Underfloor Heating Mat > Underfloor heat mat for floor heating system
Underfloor heat mat for floor heating system
USD $1 - $30
/ Meter
1000 Meters(Min.Order)
- 100000 Meter / Meters per Month
- shenzhen shanghai ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangxi, China | Brand Name | OGILLT | |
| Model Number | floor heating systems | Conductor Material | Copper | |
| Insulation Material | PVC | Jacket | PVC | |
| Number of Conductors | 2 | Application | floor heating,soil heating |
Product Description
Specification
| 150W/M2 (Parameter cable) | ||||||
| Item No. | Voltage(V) | Wattage(W) | Total Resistance (Ω) | width(M) | length(M) | Square(M2) |
| DX50-BX-150/2.0 | 220 | 300 | 160.8 | 0.5 | 4 | 2 |
| DX50-BX-150/2.5 | 220 | 375 | 129 | 0.5 | 5 | 2.5 |
| DX50-BX-150/3.0 | 220 | 450 | 106.6 | 0.5 | 6 | 3 |
| DX50-BX-150/3.5 | 220 | 525 | 92.4 | 0.5 | 7 | 3.5 |
| DX50-BX-150/4.0 | 220 | 600 | 80.2 | 0.5 | 8 | 4 |
| DX50-BX-150/4.5 | 220 | 675 | 71.8 | 0.5 | 9 | 4.5 |
| DX50-BX-150/5.0 | 220 | 750 | 64.8 | 0.5 | 10 | 5 |
| DX50-BX-150/5.5 | 220 | 825 | 58.7 | 0.5 | 11 | 5.5 |
| DX50-BX-150/6.0 | 220 | 900 | 54 | 0.5 | 12 | 6 |
| DX100-BX-150/2.0 | 220 | 300 | 160.8 | 1 | 2 | 2 |
| DX100-BX-150/2.5 | 220 | 375 | 129 | 1 | 2.5 | 2.5 |
| DX100-BX-150/3.0 | 220 | 450 | 106.6 | 1 | 3 | 3 |
| DX100-BX-150/3.5 | 220 | 525 | 92.4 | 1 | 3.5 | 3.5 |
| DX100-BX-150/4.0 | 220 | 600 | 80.2 | 1 | 4 | 4 |
| DX100-BX-150/4.5 | 220 | 675 | 71.8 | 1 | 4.5 | 4.5 |
| DX100-BX-150/5.0 | 220 | 750 | 64.8 | 1 | 5 | 5 |
| DX100-BX-150/5.5 | 220 | 825 | 58.7 | 1 | 5.5 | 5.5 |
| DX100-BX-150/6.0 | 220 | 900 | 54 | 1 | 6 | 6 |
| 180W/M2 (Parameter cable) | ||||||
| Item No. | Voltage(V) | Wattage(W) | Total Resistance (Ω) | width(M) | length(M) | Square(M2) |
| DX50-BX-180/1.85 | 220 | 330 | 148.7 | 0.5 | 3.7 | 1.9 |
| DX50-BX-180/2.25 | 220 | 400 | 116.1 | 0.5 | 4.5 | 2.3 |
| DX50-BX-180/2.75 | 220 | 500 | 97.7 | 0.5 | 5.5 | 2.8 |
| DX50-BX-180/3.15 | 220 | 570 | 83.2 | 0.5 | 6.3 | 3.2 |
| DX50-BX-180/3.65 | 220 | 650 | 73.2 | 0.5 | 7.3 | 3.7 |
| DX50-BX-180/4.0 | 220 | 720 | 63.8 | 0.5 | 8 | 4 |
| DX50-BX-180/4.5 | 220 | 810 | 58.3 | 0.5 | 9 | 4.5 |
| DX50-BX-180/5.0 | 220 | 900 | 53.4 | 0.5 | 10 | 5 |
| DX50-BX-180/5.5 | 220 | 990 | 49.5 | 0.5 | 11 | 5.5 |
| DX100-BX-180/2.0 | 220 | 360 | 134 | 1 | 2 | 2 |
| DX100-BX-180/2.5 | 220 | 450 | 107.5 | 1 | 2.5 | 2.5 |
| DX100-BX-180/3.0 | 220 | 540 | 88.8 | 1 | 3 | 3 |
| DX100-BX-180/3.5 | 220 | 630 | 77 | 1 | 3.5 | 3.5 |
| DX100-BX-180/4.0 | 220 | 720 | 66.8 | 1 | 4 | 4 |
| DX100-BX-180/4.5 | 220 | 810 | 59.9 | 1 | 4.5 | 4.5 |
| DX100-BX-180/5.0 | 220 | 900 | 54 | 1 | 5 | 5 |
| DX100-BX-180/5.5 | 220 | 990 | 49 | 1 | 5.5 | 5.5 |
| DX100-BX-180/6.0 | 220 | 1080 | 45 | 1 | 6 | 6 |
