flexible control cable
- Shenzhen Shanghai Ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangxi, China | Brand Name | Qunxing | |
| Model Number | KVV,KVVP,KVV22 | Insulation Material | PVC | |
| Type | Low Voltage | Application | Industrial | |
| Conductor Material | Copper | Jacket | PVC |
Product Description
flexible control cable
Application:
Used as interconnecting cable for measuring, controlling or regulation in control equipment for assembly and production lines, conveyors and for computer units. Suitable for fixed installations or for flexible use in conditions of light mechanical stress. Can be used outdoors when protected, and in dry or moist conditions indoors.
Standards:
GB9330
Conductor:
Flexible copper conductors to
Insulation:
PVC
Sheath:
PVC
Sheath Color:
Grey
Voltage Rating:
450/750V
Temperature Rating:
70°C
Minimum Bending Radius:
6 x overall diameter
Core Identification:
Black with White numbers. (3 cores and above to include Green/Yellow). Colored cores available.
| No. of Cores x Nominal Cross | Nominal Overall Diameter | Nominal Weight | No. of Cores x Nominal Cross | Nominal Overall Diameter | Nominal Weight |
| Sectional Area# x mm² | mm | kg/ Km | Sectional Area# x mm² | mm | kg/ Km |
| 2 x 0.50 | 4.7 | 32 | 3 x 16.00 | 18.2 | 653 |
| 2 x 0.75 | 5.1 | 39 | 4 x 0.50 | 5.4 | 46 |
| 2 x 1.00 | 5.3 | 49 | 4 x 0.75 | 5.9 | 59 |
| 2 x 1.50 | 6.2 | 61 | 4 x 1.00 | 6.5 | 69 |
| 2 x 2.50 | 7.3 | 92 | 4 x 1.50 | 7.4 | 92 |
| 3 x 0.50 | 5.1 | 39 | 4 x 2.50 | 8.5 | 148 |
| 3 x 0.75 | 5.4 | 50 | 4 x 4.00 | 10.2 | 219 |
| 3 x 1.00 | 5.6 | 60 | 4 x 6.00 | 12.3 | 323 |
| 3 x 1.50 | 6.5 | 79 | 4 x 10.00 | 15 | 513 |
| 3 x 2.50 | 7.7 | 119 | 4 x 16.00 | 19.2 | 844 |
| 3 x 4.00 | 9.3 | 176 | 4 x 25.00 | 23 | 1252 |
| 3 x 6.00 | 11 | 255 | 4 x 35.00 | 26.7 | 1658 |
| 3 x 10.00 | 14 | 411 | 4 x 50.00 | 31.5 | 2360 |
