Sanitery Adjustive Valve
- 2000 Piece / Pieces per Month
- SHANGHAI OR NINGBO
- T/T
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Control | |
| Pressure | Other, Manual-control | Power | Manual | |
| Material | Stainless Steel | Temperature of Media | Medium Temperature | |
| Media | Water | Port Size | standard | |
| Place of Origin | Jiangsu, China | Model Number | XH | |
| Brand Name | no |
Product Description
Specifications
Material:SUS304,SUS316LManual-control of pressure and flux
Application
Manual-control of pressure and flux
Working principle
XH valve is operated through a hand wheel,which gradually adjusts the conic valve plug and locks the valve plug at the proper position with the bolt.Dismountable parts on the valve are very few and with simples structures,which ensures the relibaility of the valve's opeartions and easy for uninstalls.
Standard designs
Material of valve body and valve lever with plug:
stainless steel AISI 316L or 304
Surface treatment of inner/outer side of the valve body:sandblasting polishing.
Valve lever:enforced chrome-plating treatment on the valve levers.
Material of valve wheel:stainless steel AISI 304
Standard valve is not mounted with pope fittings.Valve plug course:28mm.
Vale body,clip,lip seal and valve plug seal are same with those of XH-A valves.
Optional configuration equipment
a.Choose screw thread or clip gasket according to needed standard.
b.Asepsis valve (XH-R) is equipped with diaphragm sealed valve lever.
c.Stainless steel valve plate can be used instead of lip seal.
