Hand Labelling Machine

Specifications

YS-50 Round Bottle Labeling Machine

Please ask me for the manual and operation video if you need it!

♦Working Principle♦

Imported intelligent high-accuracy magic eye and high reliable Computer chip program controller (PLC)control the label and the case, label, using rubber roller pinned bottle the non-drying label followed the bottle in the bottle and put on rotating.

Semi-automatic Round Bottle Labeler Labeling machine,Suit for all kinds of cylindrical objects.

♦Features♦

1. Suitable for labeling round bottle in different sizes.

2. Composed by main body, sending paper, receiving paper, bottle orientation etc parts.

3. Putting the bottle to orientation part by manual and fix the bottle;

4. all metal are made of 304 stainless steel with surface finishing and special treatment, which we can guarantee you very good quality

5. small size labeling machine, very easy to operate

♦Specifications♦

Model:YS-50

Speed: 25 - 50pcs/minute

Accuracy: ±0.5mm

Applicable bottles of diameter:  Φ10-150mm

Label roll: External diameter: 300mm; Inner diameter: 75mm

Label size: width 8-150mm  length 15-210mm (standard package)

(this is standard configuration, if you need longer than this, contact us firstly, It will be customized)

Power supply: 220V/110V; 50HZ/60HZ

Power rating: 120W

Machine size: 650 (L) *450 (W) *450 (H) mm

Machine weight: 25 kg
