High quality good performance punch press machine

FOB Price

US$ 1,300 - 33,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Hunan, China
Brand Name	Lantian	Model Number	LTF
Voltage	380V	Power(W)	11kw
Weight	about 1t	Dimension(LWH)	depend on the types
Certification	CE ISO, CE ISO	Warranty	One Year
After-sales Service Provided	Engineers available to service machinery overseas

High quality good performance punch press machine

Product Description

The simple process to make charcoal briquettes is:

Carbonization Machine--Charcoal Crusher--Wheel Mixer and Liquid Mixer--Feeder--Charcoal Briquette Machien--Dryer

Name	Crusher
Model	LTWC-400, 600, 800, 1000
Power	18.5kw 30kw 45kw 60/75kw
Outlet Size	less than 5mm
Capacity	800-4000kg/h
Function	this crusher is for crushing the raw charcoal to charcoal powder

Name	Liquid Mixer / Binder Mixer
Model	LTBM-1000
Power	3kw
Capacity	Loading 0.7CBM
G. W	200kg
Function	Charcoal powder has no any adhesive, so we need to add some binder before briquetting. This mixer is for making liquid binder.

Name	Wheel Mixer
Model	LTWM-1000, 1300, 1500, 1800
Power	5.5kw, 7.5kw, 11kw
Capacity	20-120kg/cylinder
Mixing Time	5-8 minutes/time
Function	It is for mixing the charcoal powder with liquid binder evenly.

Name	Box Dryer
Model	LTOD-4, 10, 16
Power	3kw, 7kw, 11kw
Drying Time	4-8 hours
Features	Low electric consumption and the size can be customized.
Function	It is special used for drying charcoal briquettes.

Product Overviews

Model	LTYJ-9	LTYJ-48
Applicable material	Charcoal powder,coal powder,sawdust,any powder material.	Charcoal powder,coal powder,sawdust,any powder material.
Capacity	11-16 pieced/time 20-40times/min.	48pieces per time(30mm) 8-20 times/min
Motor	7.5kw(4 pole)	18.5kw(4 pole)
Diameter of briquettes	20,25,30,35,38,40mm(round) 20-40mm(cubic)	20,25,30,35,38,40mm(round) 20-40mm(cubic)
Feeding materials	≤3mm	≤3mm
Briquette shape	Round,cubic.oval or as your requirement	Round,cubic.oval or as your requirement
Pressure	40-60tons(adjustable)	40-150 tons(adjustable)
Pressure type	Mechanical pressure	Hydraulic pressure
Overal size	25009501550mm(include conveyor)	350020001800mm(include conveyor)
Packing size	150012001750mm	210021001900mm
Weight	1500kg	5500kg
