Home > Products > Sterilization Equipment > Stainless Steel Horizontal Sterilizer
Stainless Steel Horizontal Sterilizer
- Ningbo or Shanghai Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | HH | Model Number | DN1200*3000 | |
| Usage | Diary Product | Type | Autoclave | |
| Voltage | made to order | Power(W) | made to order | |
| Weight | made to order | Dimension(L*W*H) | made to order | |
| Certification | CE | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Feature :
1. Fast temperature rise .
2. The temperature inside the tank is stable with even heat distribution .
3. Energy saving
4. Indirect heating and cooling prevent twice pollution.
5. Perfect pressure control is suitable for sterilization of gas-bearing packaging .
6. Perfect temperature rise and fall are suitable for sterilization of fragile bottles.
7. Full-automatic control system .
8. Temperature and pressure record curve drawing .
9. Heat distribution test picture .
Model | RJD-500 | RJD-700 | RJD-900 | RJD-1000 | RJD-1100 | RJD-1200 | RJD-1300 | RJD-1500 | |
Sterilizing Tank | ID (mm) | 500 | 700 | 900 | 1000 | 1100 | 1200 | 1300 | 1500 |
Height (mm) | 800 | 1200 | 1500 | 2000 | 2400 | 3000 | 3750 | 3750 | |
Volume of the Inside Tank (m3) | 0.2 | 0.5 | 1 | 1.8 | 2.5 | 3.5 | 5.2 | 7 | |
Sterilizing Baskets | 1 | 2 | 2 | 2 | 3 | 4 | 4 | 4 | |
Steam Consumption kg/cycle | 85 | 150 | 250 | 285 | 350 | 385 | 420 | 500 | |
Design Temperature (°C) | 147 | ||||||||
Design Pressure (Mpa) | 0.35 | ||||||||
Steam Work Pressure (Mpa) | 0.4-0.6 | ||||||||
Cooling Water Work Pressure (MPa) | 0.3 | ||||||||
Compressed Air Work Pressure (Mpa) | 0.7 | ||||||||
Outside Sizes | L (mm) | 1150 | 1650 | 2050 | 2600 | 3050 | 3700 | 4500 | 5650 |
W (mm) | 750 | 950 | 1150 | 1250 | 1350 | 1450 | 1550 | 1750 | |
H (mm) | 1000 | 1200 | 1400 | 1500 | 1600 | 1700 | 1800 | 2050 | |
