China 3Ton wheel loader with Wooden fork
USD $23,000 - $23,000
/ Set
1 Set(Min.Order)
- 15 Set / Sets per Month
- QINGDAO
- T/T
You May Like
-
china small front end wheel loader joystick control W136
-
5T 4WD front loader with best oversea service
-
5t 3m3 bucket front loader with joystick and grapple
-
chinese professional 5ton shovel loader ZL50 with grapple and 3m3 bucket
-
front end loader, hydraulic pilot 5 ton wheel loader with low price
-
china 3m3 bucket wheel loader 6t with luxurious cabin, E-control gearbox and wet brake axle
Product Details
| Condition | New | Brand Name | QZCATER | |
| Model Number | ZL936 | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 7100*2430*3120mm | Rated Load | 3000kg | |
| Certification | CE ISO | Warranty | 1 Year | |
| After-sales Service Provided | No overseas service provided |
Product Description
Specifications
| Rated weight | 3000Kg |
| Rated capacity | 1.7m3 |
| Operating weight | 9500kg |
| Dump distance | 1200mm |
| Wheel base | 2760mm |
| Tread | 1800mm |
| Total time | 11s |
| Max. breakout force | 138KN |
| Max. dumping height | 3200mm |
| Transportation | 7050×2430×3120mm |
Engine
| Model | WEICHAI WP6G125E22 or CUMMINS 6BT5.9-C125 orYUCHAI YC6B125-T10 |
| Pattern | Turbocharger, Inline, water-cooled, 4-stroke, direct injection |
| Rated power/speed | 92kw/2200rpm |
| Max. torque | 515N.m |
Torque converter and transmission system
| Model of torque converter | YJ320B-1 |
| Pattern | 3-element single stage |
| Transmission type | Full-power shift, countershaft type |
| Number of gear | 4forward, 2 reverse |
| Max. travel speed | 40km/h |
| Axle | XUZHOU/LAIYANG |
| Main reducer pattern | Arc taper gear, model ration of first grade |
| Pattern of wheel side moderation | Planet gear moderation of single |
Tire
| Tire size | 17.5-25 |
Steering system
| Pattern | Articulated and hydraulic steering |
| Min. turning radius(outside of bucket) | 5700mm |
| Max. turning angle | 35°±1 |
Implement hydraulic system
| Implement pump | CBGV2100 |
| Displacement | 100ml/r |
| System working pressure | 27.5mpa |
| Distribution device model | DF25.2C |
Brake system
| Brake type | Air assisted oil disc on four wheel |
| Parking brake type | Soft axle control, outside bunch drum type |
