Zoomlion ZR220A Rotary Drilling Rig

FOB Price

USD $300,000 - $500,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1. Advanced technical performance
2. Reliable quality assurance
3. Reasonable structural design

ZOOMLION ZR220A Rotary Drilling Rig

Max Drilling Torque		kN.m	220
Max Drilling Diameter		mm	2000
Max Drilling Depth	Locking Mechanism	m	48
	friction type	m	60
Drill Velocity		1/min	7~26
Engine Model			Cummins QSL9
Maximum Power		kW	252
rated engine speed		1/min	2000
Bending angle of mast		º	4.5
Lifting power of Master Winch(first level)		kN	200
Lifting speed of Master Winch(first level)		m/min	62.5
Lifting speed of assist Winch(first level)		kN	110
Stress		kN	180
Pulling power		kN	200
going board rotation speed		1/min	3.2
walking speed		km/h	2.26
track gauge		mm	2300~3600
length of crawler contact ground		mm	4675
width of soleplate		mm	800
Theoretical climbing ability		%	40
Width of device in working state		mm	4400
Height of device in working state		mm	21050
Width of device in transiting state		mm	3100
Height of device in transiting state		mm	3500
Length of device in transiting state		mm	15180
Gross weight		t	70
