Hydraulic Mines Jaw Crusher With Different Specifications
- any port of China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Jaw Crusher | |
| Capacity(t/h) | 78 | Place of Origin | Shanghai, China | |
| Brand Name | Veking CANMAX | Model Number | VJ series |
Product Description
Specifications
1. Motor power range from 30-265kw2. Feeding Size: from 600*400mm to 1500*1200mm
3. Reliable quality and good price
VJ Hydraulic Jaw Type Crusher
1. By adopting heavy design, good-quality steel plate CO2 protection welding and annealing treatment, the machine frame is tight and durable;
2. The eccentric shaft is forged by alloy steel and subjected to finish turning, so that its bearing capacity is high;
3. Due to the adoption of high-quality bearings and thin oil for lubrication, it has the advantages of long service life, smooth operation and convenient maintenance;
4. Because a deep-cavity design is adopted and the rotary speed is reasonably matched with the optimized nip angle, the maximum output is guaranteed;
5. Elbow plates are unnecessarily lubricated and can protect the main machine in case of overload, so that the safety of the whole machine is improved;
6. Because the material-discharging port is hydraulically adjusted, the operation and the maintenance are convenient and quick, and the productivity is improved.
| Model | Feeding Port Size | Power | Weight | Crushing Output TPH | |||||||||||
| [mm] | [kW] | [kg] | Material-discharging Gap [mm] | ||||||||||||
| 30 | 40 | 50 | 70 | 80 | 100 | 125 | 150 | 200 | 225 | 250 | 300 | ||||
| VJ2416 | 600x400 | 30~40 | 6320 | 26 | 38 | 45 | 60 | 75 | |||||||
| VJ3020 | 750x500 | 45~60 | 8750 | 40 | 60 | 70 | 90 | 112 | 130 | ||||||
| VJ3620 | 900x500 | 60~75 | 10500 | 45 | 72 | 85 | 100 | 130 | |||||||
| VJ3624 | 900x600 | 60~75 | 14000 | 105 | 130 | 160 | 182 | ||||||||
| VJ4230 | 1,050x750 | 90~115 | 22500 | 180 | 210 | 237 | 294 | ||||||||
| VJ4832 | 1,200x800 | 115~150 | 26650 | 210 | 250 | 280 | 320 | 350 | |||||||
| VJ4840 | 1,200x1,000 | 130~150 | 44500 | 265 | 302 | 370 | 402 | ||||||||
| VJ5432 | 1,350x 800 | 135~150 | 27770 | 250 | 300 | 340 | 420 | 450 | |||||||
| VJ6040 | 1,500x1,000 | 185~255 | 50380 | 310 | 350 | 440 | 480 | 510 | |||||||
| VJ6048 | 1,500x1,200 | 185~265 | 78000 | 415 | 500 | 540 | 580 | 630 | |||||||
