Stainless Steel Wire Drawing Machine With Furnace
- Shanghai or as u need
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | wanyi | |
| Model Number | LZ | Usage | Drawing |
Product Description
Stailness steel wire production line-Model
Specifications
The stainless steel wire production line contains the wire drawing machine, annealing furnace, cooling bath, vertical take-up. Straight type wire drawing machine Composition:
1) Up draft style pay off shelf
2).LZ8/560 Straight wire drawing machine
3). SC740 I spool take up machine
4). Man-machine interface screen
5). One whole set Electrical control cabinet
Annealing furnace para:
1) For the continuous anneal line, there are 20 pipes, and the annealing furnace tube is 33
2) Annealing temperature: 800-900°C
3) Annealing speed: 15m/min
4) The outside dimension L8000XW2030XH1720 (the distance from furnace tube to ground middle is 1000mm)
5) Inside structure: inside is firebrick, middle-side is high temperature resistant wool board, outside is transported brick, outermost layer is high temperature wool board, the width of furnace chamber is 1130mm ,height of chamber is 200mm .
