China Vibrating Sieve for Sand
- Qingdao Shanghai
- T/T L/C D/P D/A
You May Like
-
Good Quality Desert Dry Magnetic Separator for Iron Ore Mining
-
China Vibrating Sieve Machine Model 1236
-
Top Quality High Intensity Dry Magnetic Separator Directly From Manufacturer
-
High Frequency Screen for Mineral Ore Mining Plant
-
High Frequency Sieve for Iron Benefication Production Line
-
Good Quality Dry Magnetic Separator for Desert Ore Mining
Product Details
| Condition | New | Type | Circular | |
| Application | Ore | Place of Origin | Henan, China | |
| Brand Name | Lanji | Model Number | 2YK1548 | |
| Voltage | 380v | Power(W) | 15kw | |
| Dimension(L*W*H) | 5420*2210*1230 | Weight | 6980 | |
| Certification | ISO9001 | Warranty | 1year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
China vibrating sieve for sand
1. Brief introduction of circular vibrating screen
LanJi Circular Vibrating Screen is widely applied in coal dressing, ore dressing, building material, electricity and chemical industries. It is doing circular movement while at work, and it is of a highly-effective, newly-developed and multilayer machine. With the introduction of eccentric shaft vibration exciter and particular block, the amplitude can be adjustable. Meanwhile, such screen has features of reliable structure, strong excited force, perfect separating efficiency, low noise, long life span, large handling capacity, and durable usage.
2. Technical parameters of circular vibrating screen:
Model | Sieve lay-er | Sieve area (m2) | Mesh size (mm) | Max feedin-g size (mm) | Capacity (m3/h) | Vibrating frequency (r/min) | Motor power (kw) | Weight (kg) | Sieve spec. (mm) |
YK1236 | 1 | 4.2 | 3-100 | 300 | 30-160 | 970 | 5.5 | 3210 | 1180×3550 |
3YK1236 | 3 | 4.2 | 3-100 | 300 | 30-160 | 970 | 11 | 4110 | 1180×3550 |
2YK1245 | 2 | 5.3 | 3-100 | 300 | 35-180 | 970 | 11 | 4320 | 1180×4450 |
3YK1245 | 3 | 5.3 | 3-100 | 300 | 35-180 | 970 | 11 | 4460 | 1180×4450 |
YK1535 | 1 | 5.1 | 3-100 | 300 | 34-200 | 970 | 11 | 4680 | 1480×3450 |
3YK1535 | 3 | 5.1 | 3-100 | 400 | 34-200 | 970 | 15 | 5710 | 1480×3450 |
YK1545 | 1 | 6.6 | 3-100 | 400 | 44-200 | 970 | 11 | 4300 | 1480×4450 |
2YK1545 | 2 | 6.6 | 3-100 | 400 | 44-258 | 970 | 15 | 4830 | 1480×4450 |
3YK1545 | 3 | 6.6 | 3-100 | 400 | 44-258 | 970 | 15 | 5832 | 1480×4450 |
4YK1545 | 4 | 6.6 | 3-100 | 400 | 44-258 | 970 | 18.5 | 6070 | 1480×4450 |
3YK1548 | 3 | 7.03 | 3-100 | 400 | 47-275 | 970 | 15 | 6540 | 1480×4750 |
4YK1548 | 4 | 7.03 | 3-100 | 200 | 47-275 | 730 | 18.5 | 6850 | 1480×4750 |
YK1848 | 1 | 8.5 | 3-100 | 400 | 56-330 | 755 | 15 | 6189 | 1780×4750 |
2YK1848 | 2 | 8.5 | 3-100 | 400 | 56-330 | 750 | 18.5 | 6539 | 1780×4750 |
3YK1848 | 3 | 8.5 | 3-100 | 400 | 56-330 | 970 | 22 | 6935 | 1780×4750 |
2YK1854 | 2 | 9.5 | 3-100 | 400 | 63-450 | 970 | 22 | 7220 | 1780×5350 |
3YK1854 | 3 | 9.5 | 3-100 | 400 | 63-450 | 970 | 22 | 7640 | 1780×5350 |
YK1860 | 1 | 10.6 | 3-100 | 400 | 56-450 | 970 | 18.5 | 7200 | 1780×5950 |
2YK2160 | 2 | 12.4 | 3-100 | 400 | 80-720 | 970 | 30 | 8240 | 2080×5950 |
3YK2160 | 3 | 12.4 | 3-100 | 400 | 80-720 | 970 | 30 | 8800 | 2080×5950 |
2YK2460 | 2 | 14.2 | 3-100 | 400 | 80-800 | 970 | 30 | 9120 | 2380×5950 |
3YK2460 | 3 | 14.2 | 3-100 | 400 | 80-800 | 970 | 30 | 9600 | 2380×5950 |
