Programmable Text Panels (MD204LV04)

Specifications

Programmable Text Panels (MD204LV04)

Product Description

MD204LV04 Text Panels (programmable text panels) is a Human-Machine Interface that is used with many kinds of PLC (or the other intelligent controllers with communication ports). With MD204LV04, both the values of the PLC inner registers and the relays status of PLC can be monitored or changed through texts or LEDs. So the operation of the machinery or the devices is more easy and convenient.

Main Features
1. The windows are made with the editor TP200 on PC. Text can be input and the PLC address can be set. The windows are downloaded with serial port.

2. The PLC communication protocols are downloaded to the MD204LV04 with the data of the windows.  So the engineer needn't program of communication.

3. It can work with most popular PLC, including SIEMENS, MITSUBISHI, OMRON, SCHNEIDER, FACON, LG, DELTA, AB, SAIA and etc. It supports some general protocols like Modbus RTU, Free communication and ECOSTEP protocol applied in KINCO Servo motor driver.

4. Password protecting function.
5. Alarm list function-The current alarm information is displayed one by one.

6. Optional clock module is available. They can provide a real-time clock.

7. It has 20 keys, which can be defined as function keys, there is a keyboard for numeric input. The manipulation is simple. Some of the mechanic buttons on the controlling cabinet can be substituted with them.

8. Various communication modes can be selected. Any of RS232, RS422 and RS485 is OK.

9. STN LCD with background lights, 4 rows (24 western characters in every row) of characters can be displayed at the same time.
10. The front panel of the MD204L accords with IP65 standard. It is waterproof and greaseproof.

Important Information about HMI Conditions

1. All of the hmi are brand new, top quality components: absolutely no used items or counterfeits.

2. The pictures are for reference only. Exact specifications should be obtained from the datasheet.

3. Prices, specifications, and availability of all items are subject to change without notice.

4. We are not responsible for typographical errors.

Payment Terms

- We accept payments made by Western Union,TT,PayPal.

-Since you made the payment successfully, you can send us the Reference NO or MTCN.

Shipping

1.We will ship the items within 5 working days after the payment is reached.

2.We ship to you by Express.

3.We are not responsible for any accidents, delays or other issues that are the responsibility of the shipping service.

4.Any import fees or charges are the buyer's responsibility.

Warranty

Warranty is available based on the following points:

1.The hmi are guaranteed for one year.

2.If the item you purchase from our company are not of perfected quality, that is they don't work electronically t   o manufacturers specifications, simply return them to us for replacement or refund.

3.If the items is defective, please notify us within 3 days of delivery.

4.Any items must be returned in their original condition to qualify for a refund or replacement.

5.The buyer is responsible for all the return shipping cost incurred.
