Home > Products > HMI & Text Panel > TK6102i Weinview HMI 10 TFT
TK6102i Weinview HMI 10 TFT
- Shanghai
- Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Weinview | |
| Model Number | TK6102i | Type | TFT |
Product Description
Specifications
TK6102i Weinview HMI 10 TFT
Features |
15" TFT LCD 1024x768 32 bit CISC CPU 500 MHz |
Specifications
Display | 15" TFT |
Brightness | 350 cd/m2 |
Color | 65536 color |
Contrast Ratio | 550:1 |
Resolution(WxH) | 1024x768 |
Back Light | CCFLx2 |
Touch Panel | 4 wires resistive type |
Touch Accuracy | 2mm |
Surface Hardness | 4H |
Serial Interface | COM1(RS232/RS485 2w/4w) COM2(RS232) COM3(RS232/RS485 2w) |
Processor | 32 bit CISC CPU 500 MHz |
Ethernet Port | 10/100 Base-T |
I/O Ports | PS/2 Port Connector |
USB Interface | USB 2.0 x 3, Mini USB Port x 1 |
Audio | Line Out x1 / MIC x 1 |
DRAM | 256MB DDR 400MHz |
IDE Interface | 44 Pins IDE interface |
RTC | Built-in |
Input Power | 24±5% VDC |
Power Consumption | 1A@24VDC |
Panel Cutout (WxH) | 352x279mm |
Weight | Approx 2.9kg |
General Specification
CE | Complies with EN50081-2 and EN50082-2 standards |
FCC | Complies with FCC Class A |
Voltage Resistance | 500 VAC (1 min) |
Isolation Resistance | Exceed 50MΩ at 500 VDC |
Vibration Endurance | 10 to 25 Hz (X,Y,Z direction 2G 30minutes) |
Protection Structure | IP65 front panel (O ring seal) |
Storage Temperature | -20~60°C |
Operating Temperature | 0~45°C |
Operation Humidity | 10-90% RH (non-condense) |
Enclosure | Aluminum |
