New and Original Weintek HMI MT Series LCD Touch Screen MT6071iP 1WV Human Machine Interface
- SHANGHAI NINGBO
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Human Machine Interface MT6070IH 3WV 7inch HMI Panel EasyView Weintek
-
Weintek Weinview MT6070iH 5WV 7 Inch HMI Human Machine Interface Touch Screen
-
Weintek HMI MT Series LCD Touch Screen MT6071iH 3WV Human Machine Interface
-
Weintek HMI MT Series LCD Touch Screen MT6071iH 5WV Human Machine Interface
-
Weinview MT6070iE 7"TFT 800 x 480 Touch Panel Com1 RS-232/RS-485 2w/4w Com3:RS-485 2w High Quality YUMO
-
Easyview Weintek 7inch Hmi Touch Screen MT6070IH we Are China Weinview Distributor
Product Details
| Brand Name | Weintek | Model Number | MT6071iP 1WV | |
| Type | Other, Other, touch screen |
Product Description
Weintek HMI MT Series LCD touch screen MT6071iP Human Machine Interface
| Display | Display: 7" TFT LCD Resolution: 800X480 Brightness: 300 Contrast Ratio: 500:1 Backlight Type: LED Backlight Life Time: >30,000hrs. Colors: 16M LED Viewing Angle(T/B/L/R): 70/50/70/70 |
| Touch Panel | Type: 4-wire Resistive Type Accuracy: Active Area Length(X)±2%,width(Y)±2% |
| Memory | Flash: 128MB RAM:128MB |
| Processor | 32 bits RISC Cortex-A8 600MHz |
| I/O Ports | USB Host: USB2.0X1 USB Client: USB 2.0X1(Micro USB) Ethernet: N/A COM Port: COM1:RS-232 COM2:RS-485 2W/4W |
| RTC | Built-in |
| Power | Input Power: 24±20%VDC Power Isolation: Built-in Power Consumption: 500mA@24VDC Voltage Resistance: 500VAC(1 min.) Isolation Resistance: Exceed 50MΩ at 500VDC Vibration Endurance: 10 to 25Hz(X,Y,Z direction 2G 30 minutes) |
| Specification | PCB Coating: N/A Enclosure: Plastic Dimensions WxHxD: 200.4X146.5X34mm Panel Cutout: 192X138mm Weight: Approx. 0.52 kg Mount: Panel mount |
| Environment | Protection Structure: NEMA4/IP65 Compliant Front Panel Storage Temperature: -20°~60°C(-4°~140°F) Operating Temperature: 0°~50°C(32°~122°F) Relative Humidity: 10%~90%(non-condensing) |
| Software | EasyBuilder Pro |
YUEQING YUMO ELECTRIC CO.,LTD
TEL:0086-577-62791815 Mobile:0086-13757779011
Sky-pe:benjaminying TradeManager:yncync
How to contact us:
Send your inquiry detail in the below for free samples, click "send "now.
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
