Home > Products > Chemical Pumps and General Industry Pumps > vegetable oil transfer pump
vegetable oil transfer pump
- Xingang/Shenzhen/Shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | An Pump | |
| Model Number | QI vegetable oil transfer pump | Theory | Centrifugal Pump | |
| Structure | Single-stage Pump | Usage | Other, end suction pump,siemens pump | |
| Power | Other, electric pump,clean water pump | Standard or Nonstandard | Other, standard,siemens pump,hot oil pump | |
| Fuel | Other, electric or diesel,diesel water pump, | Pressure | Other, high pressure pump,electric water pump, | |
| Application | Other, agricultural/industry,condensate pump,industrial water pump |
Product Description
vegetable oil transfer pump
vegetable oil transfer pump application
♦ urban water supply and drainage |
♦ central heating system water supply and sewerage |
♦ iron and steel metallurgy enterprises |
♦ paper mills |
♦ petrochemical refineries |
♦ oil fields |
♦ construction of thermal power plants and power stations |
♦ airports, chemical factories |
♦ textile mills, sugar factories |
♦ chemical plants, power stations |
♦ mines |
♦ farmland drainage irrigation and hydraulic engineering. |
vegetable oil transfer pump details
Working Principle: | Centrifugal type |
Main applications: | Chemical |
Driver: | Electric motor or Diesel engine |
Power Specs: | 220V, 240V, 380V, 400V, 415V, 440V, 50hz/60hz |
Max.permissible fluid temperature: | 105°C(221°F) |
Type of connection: | Flange |
Installation position: | Horizontal chemical pump |
Casing/Inner parts material: | Cast iron,SS 304,SS 316L,Duplex SS |
Shaft seal type: | Mechanical seal |
Maximum drive rating: | 90KW(10HP) |
Maximum caliber: | 300mm(12 inch) |
Maximum discharge-side pressure: | 1.25MPa(12.5bar) |
Maximum head: | 125m(410ft) |
Flow rate range: | 6.3-400m3/h(27.7-1760US.GPM) |
vegetable oil transfer pump parameter
Centrifugal End Suction Pump Performance | |||||
Pump Type | Capacity (m3/h) | Head (m) | Speed (rpm) | Motor Power(kw) | Eff (%) |
QI 50 | 3-14 | 3.7-82 | 1450-2900 | 0.55-11 | 21.5-60 |
QI 65 | 6-30 | 3.8-115.4 | 1450-2900 | 0.55-30 | 25-75 |
QI 80 | 12-60 | 3.6-128 | 1450-2900 | 0.55-37 | 39-75 |
QI 100 | 24.3-120 | 3.7-133 | 1450-2900 | 1.1-75 | 51-78 |
QI 125 | 51.4-240 | 8.4-133 | 1450-2900 | 4-110 | 52-81 |
QI 150 | 104-240 | 13-53 | 1450 | 11-45 | 62-81 |
QI 200 | 194-460 | 13.1-55 | 1450 | 22-90 | 65.5-82 |
QI 250 | 320-760 | 22.6-52 | 1480 | 75-132 | 67.5-84.5 |
QI 300 | 530-1200 | 21.9-38 | 1480 | 90-132 | 61.66-107.6 |
vegetable oil transfer pump structure
vegetable oil transfer pump curve
vegetable oil transfer pump packing and shipping
