8" Booster Water High Head Horizontal Suction Diesel Engine Back Pull-out Pump
- Tianjin/Shanghai/Guangzhou/Shenzhen
- T/T Credit Card PayPal
You May Like
-
Heavy Duty Electric Oil Transfer Pump
-
High Pressure Stainless Steel Mechanical Seal End Suction Centrifugal Pump
-
horizontal bare shaft centrifugal water pump for water pump
-
Horizontal end suction centrifugal pitch pump
-
Direct Connect Pipeline End Suction Pump
-
High Suction Lift Centrifugal Water Pump
Product Details
| Place of Origin | Hebei, China | Brand Name | An Pump | |
| Model Number | QI end suction condenser pump | Theory | Centrifugal Pump | |
| Structure | Single-stage Pump | Usage | Other, agriculture,industry,chemicals,mining | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, Electric or diesel | Pressure | High Pressure | |
| Application | Other, irrigation,farm,sewage,fire,water,heat,air conditioner |
Product Description
8" Booster Water High Head Horizontal Suction Diesel Engine Back Pull-out Pump
Introduction
QI series pump is single-stage , single-suction centrifugal pump , desiged as per the interational standard ISO2858 . It is a replacement of type BA water pump which is applicable to industrial and urban water supply and discharge as well as the agriculture irrigation . It can be used to transport liquid which have physical and chemical properties similar to clean water with a temperature not exceeding 80°.
QI series pump is designed according to the functions and dimensions the international standard ISO2858 requires by our company . It is suitable for hot boiler water supply , hot water circulation system , industrial and urban water supply and discharge as well as the agriculture irrigation . Nevertheless , the temperature of the water should be no more than 150°.
Specification
1.Capacity:320-760m3/h
2.Head:22.6-446.8 m
3.Speed:1480 r/min
4.Efficiency: 67.5%-84.5%
5.Power: 75-110 KW
Model Description
Horizontal Centrifugal End Suction Condenser Pump Parameter
Centrifugal End Suction Pump Performance | |||||
Pump Type | Capacity (m3/h) | Head (m) | Speed (rpm) | Motor Power(kw) | Eff (%) |
QI 50 | 3-14 | 3.7-82 | 1450-2900 | 0.55-11 | 21.5-60 |
QI 65 | 6-30 | 3.8-115.4 | 1450-2900 | 0.55-30 | 25-75 |
QI 80 | 12-60 | 3.6-128 | 1450-2900 | 0.55-37 | 39-75 |
QI 100 | 24.3-120 | 3.7-133 | 1450-2900 | 1.1-75 | 51-78 |
QI 125 | 51.4-240 | 8.4-133 | 1450-2900 | 4-110 | 52-81 |
QI 150 | 104-240 | 13-53 | 1450 | 11-45 | 62-81 |
QI 200 | 194-460 | 13.1-55 | 1450 | 22-90 | 65.5-82 |
QI 250 | 320-760 | 22.6-52 | 1480 | 75-132 | 67.5-84.5 |
QI 300 | 530-1200 | 21.9-38 | 1480 | 90-132 | 61.66-107.6 |
End Suction Condenser Pump curve
End Suction Condenser Pump Structure
End Suction Condenser Pump main feature
Working Principle: | Centrifugal type |
Main applications: | Chemical |
Driver: | Electric motor or Diesel engine |
Power Specs: | 220V, 240V, 380V, 400V, 415V, 440V, 50hz/60hz |
Max.permissible fluid temperature: | 105°C(221°F) |
Type of connection: | Flange |
Installation position: | Horizontal chemical pump |
Casing/Inner parts material: | Cast iron,SS 304,SS 316L,Duplex SS |
Shaft seal type: | Mechanical seal |
Maximum drive rating: | 90KW(10HP) |
Maximum caliber: | 300mm(12 inch) |
Maximum discharge-side pressure: | 1.25MPa(12.5bar) |
Maximum head: | 125m(410ft) |
Flow rate range: | 6.3-400m3/h(27.7-1760US.GPM) |
End Suction Condenser Pump Application
♦ urban water supply and drainage |
♦ central heating system water supply and sewerage |
♦ iron and steel metallurgy enterprises |
♦ paper mills |
♦ petrochemical refineries |
♦ oil fields |
♦ construction of thermal power plants and power stations |
♦ airports, chemical factories |
♦ textile mills, sugar factories |
♦ chemical plants, power stations |
♦ mines |
♦ farmland drainage irrigation and hydraulic engineering. |
Horizontal Centrifugal End Suction Condenser Pump Packing and shipping
Our Services
1. Offer Large capacity pump solutions
2. Selection
3. OEM available
4. ODM available
5. Design
6. Installation
7. Maintenance
Shijiazhuang An Pump Machinery Co., Ltd is a professional manufacturer of slurry pumps, sewage pumps, clean water pumps, chemical pumps, fire pumps, irrigation pumps; An Pump Machinery company has its own Kingda type selection & design, research and development team, assure to provide you efficient, energy saving slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps type design, use and maintenance program.
