HIGH SPEED INTERNAL FLAT DRIPPER IRRIGATION TAPE PRODUCTION MACHINE
- Shanghai
- T/T
You May Like
-
FULLY AUTOMATIC PP STRAPPING TAPE EXTRUSION LINE
-
CE Standard Good Quality 5mm PP Strap Making Machine
-
Good Quality Drip Irrigation Hose Production Line
-
Precision Pipe for Drip Irrigation Production Line China
-
Drip Irrigation Equipment Tubes Production Line
-
Hot Sale Labyrinth Drip Irrigation Tape Production Plant
Product Details
| Condition | New | Application | Pipe | |
| Plastic Processed | PE | Screw Design | Single-screw | |
| Automatic Grade | Automatic | Place of Origin | Shanghai, China | |
| Brand Name | Flat dripper irrigation tape production machine | Model Number | Flat dripper irrigation tape production machine | |
| Voltage | 380v | Power(W) | 130kw | |
| Dimension(L*W*H) | 40m*3m*3m | Weight | 20 tons | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Flat dripper irrigation tape production machine
1. Technical specification of flat dripper drip irrigation pipe extrusion line
1.1 Pipe Specification:
Pipe diameter | Specifications | ||
Ø12 | Ø16 | Ø20 | |
Pipe thickness | 0.15-0.4mm | 0.15-0.6 mm | 0.15-0.6 mm |
1.2 Speed:90-180m/min
1.3 Center Height: 1000MM
1.4 Installed power: about 135 kW (High speed model )
1.5 Equipment Layout (L*W*H): 25-28* 4..5*3 meter
2. Configuration of flat dripper drip irrigation pipe extrusion line
NO. | Name | Qty. |
1 | Automatic material machine and Mixed machine | 1set |
2 | Dropper recognition, transportation and insert machine | 1set |
3 | SJ60/33 Single screw extruder | 1set |
4 | Cross die head | 1set |
5 | Vacuum calibrating tank | 1set |
6 | Water cooling tank and water removing equipment | 1set |
7 | Automatic Drilling unit (Perforating unit) | 1set |
8 | Haul off | 2sets |
9 | Coiler/winder | 1set |
10 | PLC system and Electrical Control cabinet | 1set |
3. Pictures of flat dripper drip irrigation pipe extrusion line

- New Flat dripper irrigation pipe production Line ( speed l: 150m/min)
Pipe diameter | Specifications | ||
Ø12 | Ø16 | Ø20 | |
Pipe thickness | 0.2-0.4 mm | 0.2-0.9mm | 0.2-0.6mm |
Flat Dripper
- Round Drip Irrigation pipe production Line ( speed l: 80m/min)
Pipe diameter | Specifications | ||
Ø12 | Ø16 | Ø20 | |
Pipe thickness | 0.5-1.0mm | 0.5-1.5 mm | 0.5-1.5 mm |
Column Dripper

- Drip Tape Irrigation Pipe Extrusion Line (speed:. 80-120m/min)
Pipe diameter | Specifications | ||
Ø12 | Ø16 | Ø20 | |
Pipe thickness | Depending on | Customer | Requirements |
Tape Dripper


CissCo Machinery Co., has been engineering and manufacturing a series of EXTRUSION MACHINERY for more than 20 years and has thus acquired an extensive expertise in the supply of manufacturing machinery; having based ourselves on the features demanded by large companies in more than 30 countries.
Comparing with the low price low quality machine, please note our strong advantages:
1. 20 Years Experiences;
2. European Latest Technology;
3. Easy to Operate, Stable Performance, Good Quality Products, Low Production Cost;
4. Quicker Production Speed, Big Output;
5. Good Material and Well-Known Brand Electrical Parts;
6. Beautiful Appearance;
7. Free Training for Technical Process, Formula and Know-How;
8. Full Time and High Level After-Sale Services.
