High Intensity Wood Powder Machine With Low Consumption

  High Intensity Wood Powder Machine with Low Consumption

The wood powder machine, developed by Henan Kefan, is based on the advanced technology of congeneric products at home and abroad. The machine is made of the devices such as coarse crushing, milling and wind power, crushing materials with high speed impact. The wind powder makes it successful in comminution once, replacing the traditional screening process. The wood powder machine is mainly crushing solid materials of about grade 3 hardness, such as soft mineral, brittle material, tenacious material, cellulosic material, etc. and substances that are apt to coagulate into lump. The wood powder machine has fineness analyzer and is a new type powder manufacturing equipments specializing in special difficult crushing such as light material, material of fiber type, brittle and flexible material etc.

The Application of Wood Powder Machine:
The wood powder machine is used to process miscellaneous wood powder,  nutshell, Chinese herbal medicine, bark, leaf, wheat bran, mushroom, sesame, rice shell, corn cob, stalk, starch, shelled shrimps of grain type, fish flour, seaweed, dehydrated vegetable, flavoring substance, Chinese date, paper, circuit board, plastic, chemically raw material, mica, carbon, volcanic clay, perlite, distilled grain, furfural, cake type, charcoal, activated carbon, cellulose, potato slag, tea, hair, bean pulp, cotton, cow skin, sheepskin, plant root, stalk, leaf, flower, fruit, all kinds of edible fungus, etc and hundreds of difficult materials and is a ideal crusher in the industries of chemical engineering, building material, medicine, health care, breeding, food and mosquito-repellent incense, etc.

The Working Principle of Wood Powder Machine:
1.wood powder machine is from the body, the body and lower body three parts wood flour machine.
2.wood powder machine with fan, powder collector, dust composition.
3.grinding tool, 7-type knife, a cutter-type knife and centrifugal component.
4.hosting a 7-type knife grinding chamber, a centrifugal-type knives and knife, a rough grinding, fine grinding and centrifugation to resume crushing mill driven by the motor rotor high-speed operation, to produce high-speed gas flow on the grinding machine produces high-strength materials impact force, compressive force, cutting force, friction and grinding to achieve a unique function.
5.the three blade cutting wood powder machine grinding process; the rotor blades produce high-speed air flow with the direction of rotation, the material in the air flow speed and repeated shocks, cutting friction, while the role is crushed, be crushed with the flow of materials into the analyzer for analysis, due to centrifugal force by the analyzer rotor role Shiyou centripetal force by air, so when the centrifugal force is greater than the centripetal force, the fine particles with air into the powder collector to collect, coarse particles smash into the centrifuge to recovery room to smash up to achieve the fineness of your satisfaction.

Technical parameters of Wood Powder Machine:
